SPEC® CINT2006 Result

Copyright 2006-2012 Standard Performance Evaluation Corporation

ASUS Computer International (Test Sponsor: Advanced Micro Devices)

ASUS KFSN4-DRE, AMD Opteron 2350

CPU2006 license: 49 Test date: Aug-2007
Test sponsor: Advanced Micro Devices Hardware Availability: Oct-2007
Tested by: Advanced Micro Devices Software Availability: Oct-2007

SPEC has determined that this result was not in compliance with
the SPEC CPU2006 run and reporting rules. Specifically, the
submitter reported that the result would not meet the SPEC OSG
requirements for continued availability.

Benchmark results graph
Hardware
CPU Name: AMD Opteron 2350
CPU Characteristics:
CPU MHz: 2000
FPU: Integrated
CPU(s) enabled: 8 cores, 2 chips, 4 cores/chip
CPU(s) orderable: 1, 2 chips
Primary Cache: 64 KB I + 64 KB D on chip per core
Secondary Cache: 512 KB I+D on chip per core
L3 Cache: 2 MB I+D on chip per chip
Other Cache: None
Memory: 16 GB (8x2GB, DDR2-667 CL5 ECC Reg Dual Rank)
Disk Subsystem: SATA, 250 GB, 7200 RPM
Other Hardware: None
Software
Operating System: SuSE Linux Enterprise Server 10 SP1 64-bit kernel
Compiler: The Portland Group (PGI)
PGI pgcc 7.1-0 C Compiler
PGI pgCC 7.1-0 C++ Compiler
QLogic PathScale Compiler Suite
PathScale pathcc 3.0 C Compiler
PathScale pathCC 3.0 C++ Compiler
Auto Parallel: No
File System: ReiserFS
System State: Multi-user, run level 3
Base Pointers: 32/64-bit
Peak Pointers: 32/64-bit
Other Software: SmartHeap 8.0 32-bit Library for Linux

Results Table

Benchmark Base Peak
Copies Seconds Ratio Seconds Ratio Seconds Ratio Copies Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
400.perlbench NA NA NA NA NA NA NA NA NA NA NA NA NA NA
401.bzip2 NA NA NA NA NA NA NA NA NA NA NA NA NA NA
403.gcc NA NA NA NA NA NA NA NA NA NA NA NA NA NA
429.mcf NA NA NA NA NA NA NA NA NA NA NA NA NA NA
445.gobmk NA NA NA NA NA NA NA NA NA NA NA NA NA NA
456.hmmer NA NA NA NA NA NA NA NA NA NA NA NA NA NA
458.sjeng NA NA NA NA NA NA NA NA NA NA NA NA NA NA
462.libquantum NA NA NA NA NA NA NA NA NA NA NA NA NA NA
464.h264ref NA NA NA NA NA NA NA NA NA NA NA NA NA NA
471.omnetpp NA NA NA NA NA NA NA NA NA NA NA NA NA NA
473.astar NA NA NA NA NA NA NA NA NA NA NA NA NA NA
483.xalancbmk NA NA NA NA NA NA NA NA NA NA NA NA NA NA

Operating System Notes

 'ulimit -s unlimited' was used to set environment stack size
 'ulimit -l 2457600' was used to set environment locked pages in memory quantity
 'numactl' was used to bind copies to the cores
 Set vm/nr_hugepages=1200 in /etc/sysctl.conf
 mount -t hugetlbfs nodev /mnt/hugepages
 Environment variable PGI_HUGE_PAGES set to 150

General Notes

 The tested system can be assembled using a
 TRUE550 550W ATX12V power supply.

Base Compiler Invocation

C benchmarks:

 pgcc

C++ benchmarks:

 pgcpp

Base Portability Flags

400.perlbench:  -DSPEC_CPU_LP64   -DSPEC_CPU_LINUX_X64
401.bzip2:  -DSPEC_CPU_LP64
403.gcc:  -DSPEC_CPU_LP64
429.mcf:  -DSPEC_CPU_LP64
445.gobmk:  -DSPEC_CPU_LP64
456.hmmer:  -DSPEC_CPU_LP64
458.sjeng:  -DSPEC_CPU_LP64
462.libquantum:  -DSPEC_CPU_LP64   -DSPEC_CPU_LINUX
464.h264ref:  -DSPEC_CPU_LP64
483.xalancbmk:  -DSPEC_CPU_LINUX

Base Optimization Flags

C benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mipa=noarg   -Mfprelaxed   -Msmartalloc=huge:840   -tp barcelona-64   -Bstatic_pgi

C++ benchmarks:

 -fastsse   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   --zc_eh   -tp barcelona   -Bstatic_pgi

Base Other Flags

C benchmarks:

 -w

C++ benchmarks:

 -w

Peak Compiler Invocation

C benchmarks (except as noted below):

 pgcc
400.perlbench:  pathcc
403.gcc:  pathcc
445.gobmk:  pathcc
464.h264ref:  pathcc

C++ benchmarks (except as noted below):

 pgcpp
483.xalancbmk:  pathCC

Peak Portability Flags

400.perlbench:  -DSPEC_CPU_LP64   -DSPEC_CPU_LINUX_X64
401.bzip2:  -DSPEC_CPU_LP64
445.gobmk:  -DSPEC_CPU_LP64
456.hmmer:  -DSPEC_CPU_LP64
458.sjeng:  -DSPEC_CPU_LP64
462.libquantum:  -DSPEC_CPU_LP64   -DSPEC_CPU_LINUX
464.h264ref:  -DSPEC_CPU_LP64
483.xalancbmk:  -DSPEC_CPU_LINUX

Peak Optimization Flags

C benchmarks:

400.perlbench:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -Ofast   -LNO:opt=0
401.bzip2:  -Mpfi(pass 1)   -Mpfo(pass 2)   -fast   -O4   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi
403.gcc:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -m32   -O3   -OPT:Ofast
429.mcf:  -fastsse   -Mipa=fast   -Mipa=inline:1   -Msmartalloc=huge:420   -tp barcelona   -Bstatic_pgi
445.gobmk:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -OPT:alias=disjoint   -LNO:simd=0   -LNO:minvariant=off   -WOPT:retype_expr=on
456.hmmer:  -fast   -Msmartalloc=huge:448   -Mfprelaxed   -Msafeptr   -Mipa=const   -Mipa=ptr   -Mipa=arg   -tp barcelona-64   -Bstatic_pgi
458.sjeng:  -Mpfi(pass 1)   -Mipa=fast(pass 2)   -Mipa=inline:1(pass 2)   -Mipa=noarg(pass 2)   -Mpfo(pass 2)   -fast   -Msmartalloc=huge:448   -Mfprelaxed   -tp barcelona-64   -Bstatic_pgi
462.libquantum:  -fast   -Mfprelaxed   -Msmartalloc=huge:448   -Munroll=m:4   -Mipa=fast   -Mipa=inline   -Mipa=noarg   -Bstatic_pgi
464.h264ref:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -IPA:plimit=20000   -OPT:alias=disjoint   -LNO:prefetch=0

C++ benchmarks:

471.omnetpp:  basepeak = yes
473.astar:  basepeak = yes
483.xalancbmk:  -Ofast   -m32   -OPT:unroll_times_max=8   -L/cpu2006/work/cpu2006/SmartHeap -lsmartheap

Peak Other Flags

C benchmarks (except as noted below):

 -w
400.perlbench:  No flags used
403.gcc:  No flags used
445.gobmk:  No flags used
464.h264ref:  No flags used

C++ benchmarks (except as noted below):

 -w
483.xalancbmk:  No flags used

The flags file that was used to format this result can be browsed at
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.xml.
