SPEC® CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Supermicro (Test Sponsor: Advanced Micro Devices)

Supermicro H8DMU+, AMD Opteron 2360 SE

CPU2006 license: 49 Test date: Sep-2007
Test sponsor: Advanced Micro Devices Hardware Availability: Dec-2007
Tested by: Advanced Micro Devices Software Availability: Oct-2007

SPEC has determined that this result was not in compliance with
the SPEC CPU2006 run and reporting rules. Specifically, the
submitter reported that the result would not meet the 3 month
availability requirement in the SPEC CPU2006 run rules due to a
change in the availability date of the processor.

Benchmark results graph
Hardware
CPU Name: AMD Opteron 2360 SE
CPU Characteristics:
CPU MHz: 2500
FPU: Integrated
CPU(s) enabled: 8 cores, 2 chips, 4 cores/chip
CPU(s) orderable: 1,2 chips
Primary Cache: 64 KB I + 64 KB D on chip per core
Secondary Cache: 512 KB I+D on chip per core
L3 Cache: 2 MB I+D on chip per chip
Other Cache: None
Memory: 16 GB (8x2GB, DDR2-667 CL5 Reg Dual Rank)
Disk Subsystem: 1x400GB SATA, 7200 RPM
Other Hardware: None
Software
Operating System: SuSE Linux Enterprise Server 10 SP1 64-bit kernel
Compiler: The Portland Group (PGI)
PGI pgf90 7.1-0 Fortran Compiler
PGI pgcc 7.1-0 C Compiler
PGI pgCC 7.1-0 C++ Compiler
The PathScale Compiler v3.0
PathScale pathf95 3.0 Fortran Compiler
PathScale pathcc 3.0 C Compiler
PathScale pathCC 3.0 C++ Compiler
Auto Parallel: No
File System: ReiserFS
System State: Multi-user, run level 3
Base Pointers: 64-bit
Peak Pointers: 32/64-bit
Other Software: None

Results Table

Benchmark Base Peak
Copies Seconds Ratio Seconds Ratio Seconds Ratio Copies Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
410.bwaves NC NC NC NC NC NC NC NC NC NC NC NC NC NC
416.gamess NC NC NC NC NC NC NC NC NC NC NC NC NC NC
433.milc NC NC NC NC NC NC NC NC NC NC NC NC NC NC
434.zeusmp NC NC NC NC NC NC NC NC NC NC NC NC NC NC
435.gromacs NC NC NC NC NC NC NC NC NC NC NC NC NC NC
436.cactusADM NC NC NC NC NC NC NC NC NC NC NC NC NC NC
437.leslie3d NC NC NC NC NC NC NC NC NC NC NC NC NC NC
444.namd NC NC NC NC NC NC NC NC NC NC NC NC NC NC
447.dealII NC NC NC NC NC NC NC NC NC NC NC NC NC NC
450.soplex NC NC NC NC NC NC NC NC NC NC NC NC NC NC
453.povray NC NC NC NC NC NC NC NC NC NC NC NC NC NC
454.calculix NC NC NC NC NC NC NC NC NC NC NC NC NC NC
459.GemsFDTD NC NC NC NC NC NC NC NC NC NC NC NC NC NC
465.tonto NC NC NC NC NC NC NC NC NC NC NC NC NC NC
470.lbm NC NC NC NC NC NC NC NC NC NC NC NC NC NC
481.wrf NC NC NC NC NC NC NC NC NC NC NC NC NC NC
482.sphinx3 NC NC NC NC NC NC NC NC NC NC NC NC NC NC

Operating System Notes

 'ulimit -s unlimited' used to set environment stack size
 'ulimit -l 2457600' was used to set environment lock pages quantity
 'numactl' was used to bind copies to the cores
 Set vm/nr_hugepages=1200 in /etc/sysctl.conf
 mount -t hugetlbfs nodev /mnt/hugepages
 Environment variable PGI_HUGE_PAGES set to 150

General Notes

 The test system can be assembled using two
 Ablecom PWS-702A-1R 700W 12V redundant power supplies.

Base Compiler Invocation

C benchmarks:

 pgcc

C++ benchmarks:

 pgcpp

Fortran benchmarks:

 pgf95

Benchmarks using both Fortran and C:

 pgcc   pgf95

Base Portability Flags

410.bwaves:  -DSPEC_CPU_LP64
416.gamess:  -DSPEC_CPU_LP64
433.milc:  -DSPEC_CPU_LP64
434.zeusmp:  -DSPEC_CPU_LP64
435.gromacs:  -DSPEC_CPU_LP64   -Mnomain
436.cactusADM:  -DSPEC_CPU_LP64   -Mnomain
437.leslie3d:  -DSPEC_CPU_LP64
444.namd:  -DSPEC_CPU_LP64
447.dealII:  -DSPEC_CPU_LP64
450.soplex:  -DSPEC_CPU_LP64
453.povray:  -DSPEC_CPU_LP64
454.calculix:  -DSPEC_CPU_LP64   -Mnomain
459.GemsFDTD:  -DSPEC_CPU_LP64
465.tonto:  -DSPEC_CPU_LP64
470.lbm:  -DSPEC_CPU_LP64
481.wrf:  -DSPEC_CPU_LP64   -DSPEC_CPU_CASE_FLAG   -DSPEC_CPU_LINUX
482.sphinx3:  -DSPEC_CPU_LP64

Base Optimization Flags

C benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

C++ benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   --zc_eh   -tp barcelona-64   -Bstatic_pgi

Fortran benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

Benchmarks using both Fortran and C:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

Base Other Flags

C benchmarks:

 -w

C++ benchmarks:

 -w

Fortran benchmarks:

 -w

Benchmarks using both Fortran and C:

 -w

Peak Compiler Invocation

C benchmarks (except as noted below):

 pathcc
433.milc:  pgcc

C++ benchmarks (except as noted below):

 pathCC
444.namd:  pgcpp
453.povray:  pgcpp

Fortran benchmarks (except as noted below):

 pathf95
434.zeusmp:  pgf95
465.tonto:  pgf95

Benchmarks using both Fortran and C (except as noted below):

 pgcc   pgf95
436.cactusADM:  pathcc   pathf95

Peak Portability Flags

410.bwaves:  -DSPEC_CPU_LP64
416.gamess:  -DSPEC_CPU_LP64
433.milc:  -DSPEC_CPU_LP64
434.zeusmp:  -DSPEC_CPU_LP64
435.gromacs:  -DSPEC_CPU_LP64   -Mnomain
436.cactusADM:  -DSPEC_CPU_LP64   -fno-second-underscore
437.leslie3d:  -DSPEC_CPU_LP64
444.namd:  -DSPEC_CPU_LP64
453.povray:  -DSPEC_CPU_LP64
454.calculix:  -DSPEC_CPU_LP64   -Mnomain
459.GemsFDTD:  -DSPEC_CPU_LP64
465.tonto:  -DSPEC_CPU_LP64
470.lbm:  -DSPEC_CPU_LP64
481.wrf:  -DSPEC_CPU_LP64   -DSPEC_CPU_CASE_FLAG   -DSPEC_CPU_LINUX
482.sphinx3:  -DSPEC_CPU_LP64

Peak Optimization Flags

C benchmarks:

433.milc:  -Mpfi(pass 1)   -Mipa=fast(pass 2)   -Mipa=inline(pass 2)   -Mipa=noarg(pass 2)   -Mpfo(pass 2)   -fast   -O4   -Mdse   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi
470.lbm:  -Ofast
482.sphinx3:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -OPT:Ofast   -WOPT:aggstr=0   -m32

C++ benchmarks:

444.namd:  -fast   -O4   -Mfprelaxed   -Msmartalloc=huge:448   --zc_eh   -tp barcelona-64   -Mnodepchk   -Mprefetch   -Msafe_lastval   -Msafeptr=static   -Mstride0   -Munroll=n:4   -Mvect=noidiom   -Mvect=prefetch   -Bstatic_pgi
447.dealII:  -Ofast   -INLINE:aggressive=on   -OPT:malloc_alg=1   -m32   -fno-exceptions
450.soplex:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -m32   -O3   -OPT:IEEE_arith=3   -CG:load_exe=0   -CG:movnti=1   -LNO:minvariant=off   -LNO:prefetch=1   -fno-exceptions
453.povray:  basepeak = yes

Fortran benchmarks:

410.bwaves:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -OPT:Ofast   -OPT:IEEE_arith=3   -LNO:blocking=off   -LNO:ignore_feedback=off
416.gamess:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O2   -OPT:Ofast   -OPT:ro=3   -OPT:unroll_size=256
434.zeusmp:  basepeak = yes
437.leslie3d:  -Ofast   -OPT:malloc_alg=1
459.GemsFDTD:  -Ofast   -LNO:fission=2   -LNO:prefetch=0
465.tonto:  -fast   -O4   -Mfprelaxed   -Msmartalloc=huge:448   -Mipa=fast   -Mipa=inline   -Mvect=noaltcode   -tp barcelona-64   -Bstatic_pgi

Benchmarks using both Fortran and C:

435.gromacs:  -fast   -Mfpapprox=rsqrt   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi
436.cactusADM:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -LNO:prefetch=3   -LNO:prefetch_ahead=5   -LNO:ou_prod_max=10   -LNO:full_unroll=5   -ipa
454.calculix:  basepeak = yes
481.wrf:  -fast   -Mfprelaxed   -Msmartalloc=huge:448   -Mvect=noaltcode   -tp barcelona-64   -Bstatic_pgi

Peak Other Flags

C benchmarks:

433.milc:  -w

C++ benchmarks (except as noted below):

 -w
447.dealII:  -static
450.soplex:  No flags used

Fortran benchmarks:

434.zeusmp:  -w
465.tonto:  -w

Benchmarks using both Fortran and C (except as noted below):

 -w
436.cactusADM:  No flags used

The flags file that was used to format this result can be browsed at
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.xml.
