SPEC® CFP2006 Result

Copyright 2006-2016 Standard Performance Evaluation Corporation

Supermicro

Motherboard H8DM3-2 AMD Opteron 2347

CPU2006 license: 001176 Test date: Sep-2007
Test sponsor: Supermicro Hardware Availability: Sep-2007
Tested by: Supermicro Software Availability: Oct-2007

SPEC has determined that this result was not in compliance
with the SPEC CPU2006 run and reporting rules. Specifically,
the processor vendor reported that the processor would not
meet the SPEC OSG requirements for continued availability.

Benchmark results graph
Hardware
CPU Name: AMD Opteron 2347
CPU Characteristics:
CPU MHz: 1900
FPU: Integrated
CPU(s) enabled: 8 cores, 2 chips, 4 cores/chip
CPU(s) orderable: 1,2 chips
Primary Cache: 64 KB I + 64 KB D on chip per core
Secondary Cache: 512 KB I+D on chip per core
L3 Cache: 2 MB I+D on chip per chip
Other Cache: None
Memory: 16 GB (8x 2GB, PC2-5300 CL5 ECC Reg Dual Rank)
Disk Subsystem: 1x SATA, 250 GB, 7200 RPM
Other Hardware: None
Software
Operating System: SuSE Linux Enterprise Server 10 SP1 64-bit kernel
Compiler: The Portland Group (PGI)
PGI pgcc 7.1-0 C Compiler
PGI pgCC 7.1-0 C++ Compiler
PathScale Compiler Suite, Release 3.0
Auto Parallel: No
File System: ReiserFS
System State: Multi-user, run level 2
Base Pointers: 64-bit
Peak Pointers: 32/64-bit
Other Software: SmartHeap 8.0 32-bit Library for Linux

Results Table

Benchmark Base Peak
Copies Seconds Ratio Seconds Ratio Seconds Ratio Copies Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
410.bwaves NA NA NA NA NA NA NA NA NA NA NA NA NA NA
416.gamess NA NA NA NA NA NA NA NA NA NA NA NA NA NA
433.milc NA NA NA NA NA NA NA NA NA NA NA NA NA NA
434.zeusmp NA NA NA NA NA NA NA NA NA NA NA NA NA NA
435.gromacs NA NA NA NA NA NA NA NA NA NA NA NA NA NA
436.cactusADM NA NA NA NA NA NA NA NA NA NA NA NA NA NA
437.leslie3d NA NA NA NA NA NA NA NA NA NA NA NA NA NA
444.namd NA NA NA NA NA NA NA NA NA NA NA NA NA NA
447.dealII NA NA NA NA NA NA NA NA NA NA NA NA NA NA
450.soplex NA NA NA NA NA NA NA NA NA NA NA NA NA NA
453.povray NA NA NA NA NA NA NA NA NA NA NA NA NA NA
454.calculix NA NA NA NA NA NA NA NA NA NA NA NA NA NA
459.GemsFDTD NA NA NA NA NA NA NA NA NA NA NA NA NA NA
465.tonto NA NA NA NA NA NA NA NA NA NA NA NA NA NA
470.lbm NA NA NA NA NA NA NA NA NA NA NA NA NA NA
481.wrf NA NA NA NA NA NA NA NA NA NA NA NA NA NA
482.sphinx3 NA NA NA NA NA NA NA NA NA NA NA NA NA NA

Operating System Notes

 Environment stack size set to 'unlimited'
 PGI_HUGE_PAGES set to 896.
 Total number of huge pages available is 7168.

General Notes

 Product description located as of
 http://www.supermicro.com/Aplus/motherboard/Opteron2000/MCP55/H8DM3-2.cfm

Base Compiler Invocation

C benchmarks:

 pgcc

C++ benchmarks:

 pgcpp

Fortran benchmarks:

 pgf95

Benchmarks using both Fortran and C:

 pgcc   pgf95

Base Portability Flags

410.bwaves:  -DSPEC_CPU_LP64
416.gamess:  -DSPEC_CPU_LP64
433.milc:  -DSPEC_CPU_LP64
434.zeusmp:  -DSPEC_CPU_LP64
435.gromacs:  -DSPEC_CPU_LP64   -Mnomain
436.cactusADM:  -DSPEC_CPU_LP64   -Mnomain
437.leslie3d:  -DSPEC_CPU_LP64
444.namd:  -DSPEC_CPU_LP64
447.dealII:  -DSPEC_CPU_LP64
450.soplex:  -DSPEC_CPU_LP64
453.povray:  -DSPEC_CPU_LP64
454.calculix:  -DSPEC_CPU_LP64   -Mnomain
459.GemsFDTD:  -DSPEC_CPU_LP64
465.tonto:  -DSPEC_CPU_LP64
470.lbm:  -DSPEC_CPU_LP64
481.wrf:  -DSPEC_CPU_LP64   -DSPEC_CPU_CASE_FLAG   -DSPEC_CPU_LINUX
482.sphinx3:  -DSPEC_CPU_LP64

Base Optimization Flags

C benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

C++ benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   --zc_eh   -tp barcelona-64   -Bstatic_pgi

Fortran benchmarks:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

Benchmarks using both Fortran and C:

 -fast   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi

Base Other Flags

C benchmarks:

 -w

C++ benchmarks:

 -w

Fortran benchmarks:

 -w

Benchmarks using both Fortran and C:

 -w

Peak Compiler Invocation

C benchmarks (except as noted below):

 pathcc
433.milc:  pgcc

C++ benchmarks (except as noted below):

 pathCC
444.namd:  pgcpp
453.povray:  pgcpp

Fortran benchmarks (except as noted below):

 pathf95
434.zeusmp:  pgf95
465.tonto:  pgf95

Benchmarks using both Fortran and C (except as noted below):

 pgcc   pgf95
436.cactusADM:  pathcc   pathf95

Peak Portability Flags

410.bwaves:  -DSPEC_CPU_LP64
416.gamess:  -DSPEC_CPU_LP64
433.milc:  -DSPEC_CPU_LP64
434.zeusmp:  -DSPEC_CPU_LP64
435.gromacs:  -DSPEC_CPU_LP64   -Mnomain
436.cactusADM:  -DSPEC_CPU_LP64   -fno-second-underscore
437.leslie3d:  -DSPEC_CPU_LP64
444.namd:  -DSPEC_CPU_LP64
453.povray:  -DSPEC_CPU_LP64
454.calculix:  -DSPEC_CPU_LP64   -Mnomain
459.GemsFDTD:  -DSPEC_CPU_LP64
465.tonto:  -DSPEC_CPU_LP64
470.lbm:  -DSPEC_CPU_LP64
481.wrf:  -DSPEC_CPU_LP64   -DSPEC_CPU_CASE_FLAG   -DSPEC_CPU_LINUX
482.sphinx3:  -DSPEC_CPU_LP64

Peak Optimization Flags

C benchmarks:

433.milc:  -Mpfi(pass 1)   -Mipa=fast(pass 2)   -Mipa=inline(pass 2)   -Mipa=noarg(pass 2)   -Mpfo(pass 2)   -fast   -O4   -Mdse   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi
470.lbm:  -Ofast
482.sphinx3:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -OPT:Ofast   -WOPT:aggstr=0   -m32

C++ benchmarks:

444.namd:  -fast   -O4   -Mfprelaxed   -Msmartalloc=huge:448   --zc_eh   -tp barcelona-64   -Mnodepchk   -Mprefetch   -Msafe_lastval   -Msafeptr=static   -Mstride0   -Munroll=n:4   -Mvect=noidiom   -Mvect=prefetch   -Bstatic_pgi
447.dealII:  -Ofast   -INLINE:aggressive=on   -OPT:malloc_alg=1   -m32   -fno-exceptions
450.soplex:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -m32   -O3   -OPT:IEEE_arith=3   -CG:load_exe=0   -CG:movnti=1   -LNO:minvariant=off   -LNO:prefetch=1   -fno-exceptions
453.povray:  basepeak = yes

Fortran benchmarks:

410.bwaves:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -OPT:Ofast   -OPT:IEEE_arith=3   -LNO:blocking=off   -LNO:ignore_feedback=off
416.gamess:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O2   -OPT:Ofast   -OPT:ro=3   -OPT:unroll_size=256
434.zeusmp:  basepeak = yes
437.leslie3d:  -Ofast   -OPT:malloc_alg=1
459.GemsFDTD:  -Ofast   -LNO:fission=2   -LNO:prefetch=0
465.tonto:  -fast   -O4   -Mfprelaxed   -Msmartalloc=huge:448   -Mipa=fast   -Mipa=inline   -Mvect=noaltcode   -tp barcelona-64   -Bstatic_pgi

Benchmarks using both Fortran and C:

435.gromacs:  -fast   -Mfpapprox=rsqrt   -Mipa=fast   -Mipa=inline   -Mfprelaxed   -Msmartalloc=huge:448   -tp barcelona-64   -Bstatic_pgi
436.cactusADM:  -fb_create fbdata(pass 1)   -fb_opt fbdata(pass 2)   -O3   -LNO:prefetch=3   -LNO:prefetch_ahead=5   -LNO:ou_prod_max=10   -LNO:full_unroll=5   -ipa
454.calculix:  basepeak = yes
481.wrf:  -fast   -Mfprelaxed   -Msmartalloc=huge:448   -Mvect=noaltcode   -tp barcelona-64   -Bstatic_pgi

Peak Other Flags

C benchmarks:

433.milc:  -w

C++ benchmarks (except as noted below):

 -w
447.dealII:  -static
450.soplex:  No flags used

Fortran benchmarks:

434.zeusmp:  -w
465.tonto:  -w

Benchmarks using both Fortran and C (except as noted below):

 -w
436.cactusADM:  No flags used

The flags file that was used to format this result can be browsed at
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.01.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/cpu2006/flags/amd814GH-flags.20090714.01.xml.
