SPECjbb2005 SPECjbb2005 bops = 2461117, SPECjbb2005 bops/JVM = 153820
IBM Corporation IBM System x3755 M3
IBM Corporation IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)

JVM run JVM Scores
1155907
2153357
3155180
4151625
5155082
6153637
7154357
8153113
9153904
10153689
11153255
12154109
13150665
14154401
15154345
16154491
SPECjbb2005 bops = 2461117, SPECjbb2005 bops/JVM = 153820

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM System x3755 M3
Processor AMD Opteron 6282 SE (AMD Turbo Core up to 3.3GHz)
MHz 2600
# of Chips 4
# of Cores 64
# of Cores/Chip 16
HW Threading Enabled? No
Procs Avail to Java 64
Memory (MB) 262144
Memory Details 32 x 8 GB 2Rx4 PC3L-10600R-09, ECC; slots 1-32 populated
Primary cache 512 KB I + 256 KB D on chip per chip
Secondary cache 16 MB I+D on chip per chip, 2 MB shared / 2 cores
Other cache 16 MB I+D on chip per chip, 8 MB shared / 8 cores
Filesystem NTFS
Disks 1 x 250GB 7.2K RPM SATA
Other hardware N/A
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)
JVM Command Line -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -Xlp spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 1875
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH C:\IBM\Java60\jre\bin\compressedrefs\jclSC160\vm.jar;
C:\IBM\Java60\jre\lib\annotation.jar;
C:\IBM\Java60\jre\lib\beans.jar;
C:\IBM\Java60\jre\lib\java.util.jar;
C:\IBM\Java60\jre\lib\jndi.jar;
C:\IBM\Java60\jre\lib\logging.jar;
C:\IBM\Java60\jre\lib\security.jar;
C:\IBM\Java60\jre\lib\sql.jar;
C:\IBM\Java60\jre\lib\ibmorb.jar;
C:\IBM\Java60\jre\lib\ibmorbapi.jar;
C:\IBM\Java60\jre\lib\ibmcfw.jar;
C:\IBM\Java60\jre\lib\rt.jar;
C:\IBM\Java60\jre\lib\charsets.jar;
C:\IBM\Java60\jre\lib\resources.jar;
C:\IBM\Java60\jre\lib\ibmpkcs.jar;
C:\IBM\Java60\jre\lib\ibmcertpathfw.jar;
C:\IBM\Java60\jre\lib\ibmjgssfw.jar;
C:\IBM\Java60\jre\lib\ibmjssefw.jar;
C:\IBM\Java60\jre\lib\ibmsaslfw.jar;
C:\IBM\Java60\jre\lib\ibmjcefw.jar;
C:\IBM\Java60\jre\lib\ibmjgssprovider.jar;
C:\IBM\Java60\jre\lib\ibmjsseprovider2.jar;
C:\IBM\Java60\jre\lib\ibmcertpathprovider.jar;
C:\IBM\Java60\jre\lib\ibmxmlcrypto.jar;
C:\IBM\Java60\jre\lib\management-agent.jar;
C:\IBM\Java60\jre\lib\xml.jar;
C:\IBM\Java60\jre\lib\jlm.jar;
C:\IBM\Java60\jre\lib\javascript.jar
OS Version Microsoft Windows Server 2008 R2 Enterprise x64 SP1
Other software N/A
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Taipei, Taiwan
Test date Nov 4, 2011
H/w available Dec-2011
JVM available Jun-2009
OS available Mar-2011
Other s/w available N/A
AOT Compilation

Tuning
  • Affinity Masks set to 0xF,0xF0,0xF00,0xF000,0xF0000,0xF00000,0xF000000,
    0xF0000000,0xF00000000,0xF000000000,0xF0000000000,0xF00000000000
    ,0xF000000000000,0xF0000000000000,0xF00000000000000,0xF000000000000000
  • Windows Power Profile set to High Performance.
  • Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
  • BIOS Settings
    • 'Operating mode' set to 'Custom'
    • HT Link Speed: HT3.
    • Non-cohernet width: 16 Bits.
    • Message Triggered C1E: Enable.
    • P-State Support: Enable.
    • Memory Speed: 1333MHz.
    • 'DRAM Prefetch Triggered by CPU Request' Disable
    • 'DRAM Prefetch Trigger by I/O Requests' Disable
    • 'Hardware Prefetches' Enable
    • 'Software Prefetches' Enable
    • ASPM: Disable.
    • Node Interleave: Disable.
    • Core Performance Boost: Enable.
Notes
"None"

JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 45815
2 90058
3 136124
4 157104 *
5 157354 *
6 156006 *
7 155087 *
8 153986 *
SPECjbb2005 (from 4 to 8) 155907 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44790
2 90826
3 135330
4 154492 *
5 154014 *
6 153614 *
7 152511 *
8 152154 *
SPECjbb2005 (from 4 to 8) 153357 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44706
2 92606
3 135743
4 156866 *
5 155637 *
6 154665 *
7 154446 *
8 154286 *
SPECjbb2005 (from 4 to 8) 155180 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 45607
2 89963
3 132290
4 152177 *
5 152565 *
6 151710 *
7 151053 *
8 150623 *
SPECjbb2005 (from 4 to 8) 151625 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44136
2 108075
3 133948
4 156458 *
5 155018 *
6 155607 *
7 154844 *
8 153483 *
SPECjbb2005 (from 4 to 8) 155082 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 45000
2 89142
3 134295
4 153926 *
5 155690 *
6 153809 *
7 152981 *
8 151779 *
SPECjbb2005 (from 4 to 8) 153637 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 47734
2 92553
3 135988
4 156133 *
5 154262 *
6 154592 *
7 153640 *
8 153158 *
SPECjbb2005 (from 4 to 8) 154357 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 47295
2 107744
3 126166
4 156305 *
5 154360 *
6 151998 *
7 151159 *
8 151744 *
SPECjbb2005 (from 4 to 8) 153113 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 46841
2 104421
3 129260
4 155557 *
5 155002 *
6 154110 *
7 152193 *
8 152656 *
SPECjbb2005 (from 4 to 8) 153904 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44494
2 87069
3 134170
4 155547 *
5 154298 *
6 154196 *
7 152814 *
8 151588 *
SPECjbb2005 (from 4 to 8) 153689 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 47186
2 108954
3 133687
4 153487 *
5 154393 *
6 153636 *
7 152849 *
8 151908 *
SPECjbb2005 (from 4 to 8) 153255 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43903
2 94226
3 133135
4 155554 *
5 154718 *
6 154600 *
7 153468 *
8 152204 *
SPECjbb2005 (from 4 to 8) 154109 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44082
2 92642
3 131540
4 151580 *
5 151610 *
6 150890 *
7 149481 *
8 149763 *
SPECjbb2005 (from 4 to 8) 150665 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 46317
2 91396
3 136076
4 155987 *
5 154595 *
6 154343 *
7 153280 *
8 153799 *
SPECjbb2005 (from 4 to 8) 154401 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 46428
2 88964
3 134464
4 155392 *
5 155463 *
6 154756 *
7 153303 *
8 152814 *
SPECjbb2005 (from 4 to 8) 154345 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 45549
2 86938
3 133284
4 156266 *
5 154913 *
6 153610 *
7 153985 *
8 153681 *
SPECjbb2005 (from 4 to 8) 154491 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Nov 4, 2011
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 30-Nov-2011
