SPEC® OMPG2012 Result

Intel	SPECompG_base2012 = NC
Intel R2308WTTYS (Intel Xeon E5-2699 v4, 2.2GHz, DDR4-2133 MHz,SMT ON Turbo ON)	SPECompG_peak2012 = NC

OMP2012 license:	13	Test date:	Mar-2016
Test sponsor:	Intel	Hardware Availability:	Mar-2016
Tested by:	Intel	Software Availability:	Feb-2016

SPEC has determined that this result was not in compliance
with the SPEC OMP2012 run and reporting rules. Specifically,
the submitter reported that the result used an unsupported
version of the Operating System. Results using a supported OS
can be found at http://www.spec.org/omp2012/results/res2016q2/omp2012-20160530-00076.html .

Hardware
CPU Name:	Intel Xeon E5-2699 v4
CPU Characteristics:	Intel Turbo Boost Technology up to 3.60 GHz
CPU MHz:	2200
CPU MHz Maximum:	3600
FPU:	Integrated
CPU(s) enabled:	44 cores, 2 chips, 22 cores/chip, 2 threads/core
CPU(s) orderable:	1,2 Chips
Primary Cache:	32 KB I + 32 KB D on chip per core
Secondary Cache:	256 KB I+D on chip per core
L3 Cache:	55 MB I+D on chip per chip
Other Cache:	None
Memory:	128 GB (8 x 16 GB 2Rx4 PC4-2400U-R, running at 2133Mhz)
Disk Subsystem:	NFS via 10GBPS Ethernet
Other Hardware:	--
Base Threads Run:	88
Minimum Peak Threads:	44
Maximum Peak Threads:	88

Software
Operating System:	Red Hat Enterprise Linux Server release 6.4, Kernel 2.6.32-358.el6.x86_64
Compiler:	C/C++/Fortran: Version 14.0.4.211 of Intel Composer XE for Linux Build 20140805 C/C++/Fortran: Version 16.0.2.181 of Intel Composer XE for Linux Build 20160204
Auto Parallel:	No
File System:	Linux ext3
System State:	Default
Base Pointers:	64-bit
Peak Pointers:	64-bit
Other Software:	None

Results Table

Benchmark	Base							Peak
Benchmark	Threads	Seconds	Ratio	Seconds	Ratio	Seconds	Ratio	Threads	Seconds	Ratio	Seconds	Ratio	Seconds	Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
350.md	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
351.bwaves	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
352.nab	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
357.bt331	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
358.botsalgn	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
359.botsspar	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
360.ilbdc	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
362.fma3d	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
363.swim	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
367.imagick	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
370.mgrid331	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
371.applu331	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
372.smithwa	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC
376.kdtree	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC	NC

Submit Notes

The config file option 'submit' was used.

Platform Notes

 Sysinfo program /root/pshelepu/SpecOMP/Docs/sysinfo
 $Rev: 395 $ $Date:: 2012-07-25 #$ 8f8c0fe9e19c658963a1e67685e50647
 running on bdw-ep2 Tue Mar 15 05:38:45 2016

 This section contains SUT (System Under Test) info as seen by
 some common utilities.  To remove or add to this section, see:
   http://www.spec.org/omp2012/Docs/config.html#sysinfo

 From /proc/cpuinfo
    model name : Intel(R) Xeon(R) CPU E5-2699 v4 @ 2.20GHz
       2 "physical id"s (chips)
       88 "processors"
    cores, siblings (Caution: counting these is hw and system dependent.  The
    following excerpts from /proc/cpuinfo might not be reliable.  Use with
    caution.)
       cpu cores : 22
       siblings  : 44
       physical 0: cores 0 1 2 3 4 5 8 9 10 11 12 16 17 18 19 20 21 24 25 26 27
       28
       physical 1: cores 0 1 2 3 4 5 8 9 10 11 12 16 17 18 19 20 21 24 25 26 27
       28
    cache size : 56320 KB

 From /proc/meminfo
    MemTotal:       132020108 kB
    HugePages_Total:       0
    Hugepagesize:       2048 kB

 /usr/bin/lsb_release -d
    Red Hat Enterprise Linux Server release 6.4 (Santiago)

 From /etc/*release* /etc/*version*
    redhat-release: Red Hat Enterprise Linux Server release 6.4 (Santiago)
    system-release: Red Hat Enterprise Linux Server release 6.4 (Santiago)
    system-release-cpe: cpe:/o:redhat:enterprise_linux:6server:ga:server

 uname -a:
    Linux bdw-ep2 2.6.32-358.el6.x86_64 #1 SMP Tue Jan 29 11:47:41 EST 2013
    x86_64 x86_64 x86_64 GNU/Linux

 run-level 3 Mar 5 05:55

 SPEC is set to: /root/pshelepu/SpecOMP
    Filesystem    Type    Size  Used Avail Use% Mounted on
    /dev/mapper/vg_hswep2-lv_root
                  ext4     50G   39G  8.6G  82% /

 Additional information from dmidecode:
   BIOS Intel Corporation GRRFSDP1.86B.0271.R00.1510301446 10/30/2015
   Memory:
    8x   16 GB
    8x 0x11 Unknown 16 GB 2134 MHz 1 rank
    8x NO DIMM Unknown   2400 MHz 2 rank
    8x NO DIMM Unknown   2400 MHz 3 rank

 (End of data from sysinfo program)

General Notes

 ========================================================================
 General base OMP Library Settings
   ENV_KMP_AFFINITY=compact,0

 ========================================================================
 General peak OMP Library Settings
   ENV_KMP_AFFINITY=compact,0

 ========================================================================
 General OMP Library Settings
   KMP_LIBRARY=turnaround
   KMP_STACKSIZE=256M
   KMP_BLOCKTIME=infinite
   OMP_DYNAMIC=FALSE
   OMP_NESTED=FALSE
   OMP_SCHEDULE=static
 ========================================================================
 Compiler selection proxy script spec{icc/ifort/icpc/run} was used:
 #!/bin/sh
 COMPBIN=${BASH_SOURCE[0]:-$0}
 COMPBIN=${COMPBIN##*/spec}
 version=$1
 shift

 COMPILER_ROOT_PATHS="/home/tools/compilers"

 for COMPILER_ROOT_PATH in $COMPILER_ROOT_PATHS ; do
 if [ -e "$COMPILER_ROOT_PATH/${version}/bin/compilervars.sh" ] ; then
 . $COMPILER_ROOT_PATH/${version}/bin/compilervars.sh intel64
 break
 fi
 done

 exec $COMPBIN "$@"
 for specrun last line is
 exec "$@"
 Compiler for base and most peak: C/C++/Fortran: Version 14.0.4.211 of Intel Composer XE for Linux Build 20140805
 Compiler for some peak components (where 2016u2 is specified): C/C++/Fortran: Version 16.0.2.181 of Intel Composer XE for Linux Build 20160204
 ========================================================================
 351.bwaves:peak:
   ENV_KMP_AFFINITY=compact,1
   ENV_OMP_SCHEDULE=static,1

 ========================================================================
 359.botsspar:peak:
   ENV_KMP_AFFINITY=compact,1
   ENV_OMP_SCHEDULE=guided

 ========================================================================
 363.swim:peak:
   ENV_KMP_AFFINITY=compact,1

 ========================================================================
 370.mgrid331:peak:
   ENV_KMP_AFFINITY=compact,1

 ========================================================================
 372.smithwa:peak:
   ENV_OMP_SCHEDULE=static,1

Base Compiler Invocation

Base Portability Flags

350.md:	-FR
357.bt331:	-mcmodel=medium
363.swim:	-mcmodel=medium
367.imagick:	-std=c99

Base Optimization Flags

C benchmarks:

-O3 -openmp -ipo -xCORE-AVX2 -ansi-alias

C++ benchmarks:

-O3 -openmp -ipo -xCORE-AVX2 -ansi-alias

Fortran benchmarks:

-O3 -openmp -ipo -xCORE-AVX2 -align array64byte

Peak Compiler Invocation

C benchmarks (except as noted below):

	specicc 2016u2
359.botsspar:	specicc 2013_sp1.4.211
372.smithwa:	specicc 2013_sp1.4.211

C++ benchmarks:

specicpc 2013_sp1.4.211

Fortran benchmarks (except as noted below):

	specifort 2013_sp1.4.211
350.md:	specifort 2016u2
371.applu331:	specifort 2016u2

Peak Portability Flags

350.md:	-FR
357.bt331:	-mcmodel=medium
363.swim:	-mcmodel=medium
367.imagick:	-std=c99

Peak Optimization Flags

C benchmarks:

352.nab:	-O3 -qopenmp -ipo -xCORE-AVX2 -fno-alias -opt-malloc-options=1 -opt-calloc -fp-model fast=2 -no-prec-div -no-prec-sqrt -ansi-alias
358.botsalgn:	-O3 -qopenmp -ipo -xCORE-AVX2 -fno-alias -ansi-alias
359.botsspar:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -ansi-alias
367.imagick:	-O3 -qopenmp -ipo -xCORE-AVX2 -ansi-alias
372.smithwa:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -opt-streaming-stores always -opt-malloc-options=1 -ansi-alias

C++ benchmarks:

-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -ansi-alias

Fortran benchmarks:

350.md:	-O3 -qopenmp -ipo -xCORE-AVX2 -fno-alias -opt-malloc-options=1 -fp-model fast=2 -no-prec-div -no-prec-sqrt -align array64byte
351.bwaves:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -fp-model fast=2 -no-prec-div -no-prec-sqrt -align array64byte
357.bt331:	Same as 351.bwaves
360.ilbdc:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -align array64byte
362.fma3d:	Same as 360.ilbdc
363.swim:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -opt-streaming-stores always -opt-malloc-options=3 -align array64byte
370.mgrid331:	-O3 -openmp -ipo -xCORE-AVX2 -fno-alias -opt-malloc-options=3 -align array64byte
371.applu331:	-O3 -qopenmp -ipo -xCORE-AVX2 -align array64byte

The flags file that was used to format this result can be browsed at
http://www.spec.org/omp2012/flags/Intel-ic13.0-linux64.20160331.00.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/omp2012/flags/Intel-ic13.0-linux64.20160331.00.xml.
