SPEC® OMPG2012 Result

Copyright 2012-2017 Standard Performance Evaluation Corporation

Huawei

SPECompG_base2012 = 39.3

Huawei 2488H V5 (Intel Xeon Platinum 8180)

SPECompG_peak2012 = 40.1

OMP2012 license: 27 Test date: Jun-2017
Test sponsor: Huawei Hardware Availability: Jul-2017
Tested by: Huawei Software Availability: Apr-2017
Benchmark results graph
Hardware
CPU Name: Intel Xeon Platinum 8180
CPU Characteristics: Intel Turbo Boost Technology up to 3.80 GHz
CPU MHz: 2500
CPU MHz Maximum: 3800
FPU: Integrated
CPU(s) enabled: 112 cores, 4 chips, 28 cores/chip, 2 threads/core
CPU(s) orderable: 2, 4 Chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 1 MB I+D on chip per core
L3 Cache: 38.5 MB I+D on chip per chip
Other Cache: None
Memory: 768 GB (24 x 32 GB 2Rx4 PC4-2666V, running at
2666 MHz)
Disk Subsystem: 2 x 600 GB 10K RPM SAS
Other Hardware: None
Base Threads Run: 224
Minimum Peak Threads: 112
Maximum Peak Threads: 224
Software
Operating System: Red Hat Enterprise Linux Server 7.3
(Maipo)
Linux Kernel 3.10.0-514.el7.x86_64
Compiler: C/C++/Fortran: Version 17.0.4.196 of Intel
Parallel Studio XE 2017
for Linux;
Auto Parallel: No
File System: xfs
System State: run-level 3
Base Pointers: 64-bit
Peak Pointers: 64-bit
Other Software: None

Results Table

Benchmark Base Peak
Threads Seconds Ratio Seconds Ratio Seconds Ratio Threads Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
350.md 224 65.3  70.9  69.5  66.7  69.7  66.5  224 68.2  67.9  68.2  67.9  67.9  68.1
351.bwaves 224 112    40.6  111    40.7  111    40.7  112 108    41.8  108    41.8  108    41.8
352.nab 224 112    34.8  112    34.8  112    34.8  224 112    34.8  112    34.8  112    34.8
357.bt331 224 99.9  47.4  100    47.2  100    47.4  224 99.9  47.4  100    47.2  100    47.4
358.botsalgn 224 117    37.1  117    37.1  117    37.1  224 117    37.1  117    37.1  117    37.1
359.botsspar 224 215    24.4  217    24.2  216    24.3  224 215    24.4  217    24.2  216    24.3
360.ilbdc 224 133    26.8  133    26.8  132    27.0  224 131    27.1  132    27.0  132    27.0
362.fma3d 224 148    25.7  147    25.9  148    25.6  224 129    29.4  130    29.1  131    29.1
363.swim 224 149    30.4  149    30.5  148    30.6  112 147    30.7  146    31.0  147    30.9
367.imagick 224 139    50.7  139    50.6  139    50.4  224 139    50.7  139    50.6  139    50.4
370.mgrid331 224 166    26.6  165    26.8  166    26.7  112 153    29.0  153    28.9  153    28.9
371.applu331 224 117    51.6  117    51.9  120    50.4  224 117    51.9  114    53.0  116    52.2
372.smithwa 224 57.6  93.1  57.4  93.4  57.2  93.7  112 58.6  91.5  56.9  94.2  57.2  93.6
376.kdtree 224 118    38.0  118    38.0  118    38.0  224 119    37.8  118    38.1  118    38.0

Platform Notes

 Sysinfo program /omp2012/Docs/sysinfo
 $Rev: 395 $ $Date:: 2012-07-25 #$ 8f8c0fe9e19c658963a1e67685e50647
 running on myhost1 Tue Jun 13 00:19:59 2017

 This section contains SUT (System Under Test) info as seen by
 some common utilities.  To remove or add to this section, see:
   http://www.spec.org/omp2012/Docs/config.html#sysinfo

 From /proc/cpuinfo
    model name : Intel(R) Xeon(R) Platinum 8180 CPU @ 2.50GHz
       4 "physical id"s (chips)
       224 "processors"
    cores, siblings (Caution: counting these is hw and system dependent.  The
    following excerpts from /proc/cpuinfo might not be reliable.  Use with
    caution.)
       cpu cores : 28
       siblings  : 56
       physical 0: cores 0 1 2 3 4 5 6 8 9 10 11 12 13 14 16 17 18 19 20 21 22 24
       25 26 27 28 29 30
       physical 1: cores 0 1 2 3 4 5 6 8 9 10 11 12 13 14 16 17 18 19 20 21 22 24
       25 26 27 28 29 30
       physical 2: cores 0 1 2 3 4 5 6 8 9 10 11 12 13 14 16 17 18 19 20 21 22 24
       25 26 27 28 29 30
       physical 3: cores 0 1 2 3 4 5 6 8 9 10 11 12 13 14 16 17 18 19 20 21 22 24
       25 26 27 28 29 30
    cache size : 39424 KB

 From /proc/meminfo
    MemTotal:       790643032 kB
    HugePages_Total:   24576
    Hugepagesize:       2048 kB

 From /etc/*release* /etc/*version*
    os-release:
       NAME="Red Hat Enterprise Linux Server"
       VERSION="7.3 (Maipo)"
       ID="rhel"
       ID_LIKE="fedora"
       VERSION_ID="7.3"
       PRETTY_NAME="Red Hat Enterprise Linux Server 7.3 (Maipo)"
       ANSI_COLOR="0;31"
       CPE_NAME="cpe:/o:redhat:enterprise_linux:7.3:GA:server"
    redhat-release: Red Hat Enterprise Linux Server release 7.3 (Maipo)
    system-release: Red Hat Enterprise Linux Server release 7.3 (Maipo)
    system-release-cpe: cpe:/o:redhat:enterprise_linux:7.3:ga:server

 uname -a:
    Linux myhost1 3.10.0-514.el7.x86_64 #1 SMP Wed Oct 19 11:24:13 EDT 2016
    x86_64 x86_64 x86_64 GNU/Linux

 run-level 3 Jun 12 22:00

 SPEC is set to: /omp2012
    Filesystem              Type  Size  Used Avail Use% Mounted on
    /dev/mapper/rhel00-root xfs   187G   53G  134G  29% /

 Additional information from dmidecode:
   BIOS INSYDE Corp. 0.09 03/29/2017
   Memory:
    8x NO DIMM NO DIMM
    24x Samsung M393A4K40BB2-CTD 32 GB 2666 MHz 2 rank

 (End of data from sysinfo program)

General Notes

 ========================================================================
 Power profile set with:
 cpupower -c all frequency-set -g performance

 System settings notes:
 Intel Turbo Boost Technology (Turbo)  : Enabled
 Memory RAS Configuration set to Maximum Performance

 ========================================================================
 General Notes and Enviroment variables
   ENV_KMP_BLOCKTIME=infinite
   ENV_KMP_DETERMINISTIC_REDUCTION=1
   ENV_OMP_DYNAMIC=FALSE
   ENV_KMP_LIBRARY=turnaround
   ENV_KMP_SCHEDULE=static,balanced
   ENV_KMP_STACKSIZE=256M
   ENV_OMP_NESTED=FALSE
   ENV_OMP_NUM_THREADS=224

 ========================================================================
 General base OMP Library Settings
   ENV_KMP_AFFINITY=granularity=fine,proclist=[0-55,112-167,56-111,168-223],explicit

 ========================================================================
 General peak OMP Library Settings
   ENV_KMP_AFFINITY=compact,1

 ========================================================================
 Per benchmark peak OMP Library Settings

 ========================================================================
 351.bwaves:peak:
   ENV_KMP_AFFINITY=compact,1
   ENV_OMP_SCHEDULE=static,1

 ========================================================================
 359.botsspar:peak:
   ENV_KMP_AFFINITY=compact,1
   ENV_OMP_SCHEDULE=guided

 ========================================================================
 363.swim:peak:
   ENV_KMP_AFFINITY=compact,1

 ========================================================================
 371.applu331:peak:
   ENV_KMP_AFFINITY=granularity=fine,proclist=[0-55,112-167,56-111,168-223],explicit

 ========================================================================
 372.smithwa:peak:
   ENV_KMP_AFFINITY=compact,1

Base Compiler Invocation

C benchmarks:

 icc

C++ benchmarks:

 icpc

Fortran benchmarks:

 ifort

Base Portability Flags

350.md:  -FR
357.bt331:  -mcmodel=medium
363.swim:  -mcmodel=medium
367.imagick:  -std=c99

Base Optimization Flags

C benchmarks:

 -O3   -qopenmp   -ipo    -xCORE-AVX512   -fp-model fast=2   -no-prec-div   -no-prec-sqrt   -ansi-alias

C++ benchmarks:

 -O3   -qopenmp   -ipo    -xCORE-AVX512   -fp-model fast=2   -no-prec-div   -no-prec-sqrt   -ansi-alias

Fortran benchmarks:

 -O3   -qopenmp   -ipo    -xCORE-AVX512   -fp-model fast=2   -no-prec-div   -no-prec-sqrt   -align all

Peak Compiler Invocation

C benchmarks:

 icc

C++ benchmarks:

 icpc

Fortran benchmarks:

 ifort

Peak Portability Flags

350.md:  -FR
357.bt331:  -mcmodel=medium
363.swim:  -mcmodel=medium
367.imagick:  -std=c99

Peak Optimization Flags

C benchmarks:

352.nab:  basepeak = yes
358.botsalgn:  basepeak = yes
359.botsspar:  basepeak = yes
367.imagick:  basepeak = yes
372.smithwa:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -opt-streaming-stores always   -opt-malloc-options=1   -ansi-alias

C++ benchmarks:

 -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -ansi-alias

Fortran benchmarks:

350.md:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -opt-malloc-options=1   -fp-model fast=2   -no-prec-div   -no-prec-sqrt   -align array64byte
351.bwaves:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -fp-model fast=2   -no-prec-div   -no-prec-sqrt   -align array64byte
357.bt331:  basepeak = yes
360.ilbdc:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -align array64byte
362.fma3d:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -no-prec-div   -no-prec-sqrt
363.swim:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -opt-streaming-stores always   -opt-malloc-options=3   -align all
370.mgrid331:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -fno-alias   -opt-malloc-options=3   -fp-model strict
371.applu331:  -O3   -qopenmp   -ipo    -xCORE-AVX512   -align all

The flags file that was used to format this result can be browsed at
http://www.spec.org/omp2012/flags/Intel-ic13.0-linux64.20170711.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/omp2012/flags/Intel-ic13.0-linux64.20170711.xml.
