Hardware |
|---|
| Hardware Vendor |
SuperMicro, Inc. |
| Vendor URL |
http://www.supermicro.com/ |
| Model |
X7DBE |
| Processor |
Intel Xeon 5160 |
| MHz |
3000 |
| # of Chips |
2 |
| # of Cores |
4 |
| # of Cores/Chip |
2 |
| HW Threading Enabled? |
No |
| Procs Avail to Java |
4 |
| Memory (MB) |
8192 |
| Memory Details |
8 x 1GB DDR2-667 CL5 FBDIMM |
| Primary cache |
32KB(I) + 32KB(D) on chip, per core |
| Secondary cache |
4096KB(I+D) on chip, shared |
| Other cache |
|
| Filesystem |
NTFS |
| Disks |
1 x 250GB SATA |
| Other hardware |
|
|
|
Software |
|---|
| Software Vendor |
IBM Corporation |
| Vendor URL |
http://www.ibm.com/ |
| JVM Version |
IBM J9 VM (build 2.3, J2RE 1.5.0 IBM J9 2.3 Windows Server 2003 x86-32 j9vmwi3223-20060919 (JIT enabled) |
| JVM Command Line |
start /B %JAVA% -Xgcpolicy:gencon -Xjvm:perf -XlockReservation -Xlp -Xmn1000m -Xms1500m -Xmx1500m -Xnoloa -XtlhPrefetch spec.jbb.JBBmain -propfile %PROPFILE% |
| JVM Initial Heap Memory (MB) |
1536 |
| JVM Maximum Heap Memory (MB) |
1536 |
| JVM Address bits |
32 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\java\IBM32-sdk-50-2.0.2\jre\bin\perf\jclSC150\vm.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\core.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\charsets.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\graphics.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\security.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmpkcs.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmorb.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmcfw.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmorbapi.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjcefw.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjgssprovider.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjsseprovider2.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjaaslm.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjaasactivelm.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmcertpathprovider.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\server.jar;
C:\java\IBM32-sdk-50-2.0.2\jre\lib\xml.jar |
| OS Version |
Microsoft Windows Server 2003 Enterprise x64 Edition SP1 (64-bit) |
| Other software |
|
|
|
Test Information |
|---|
| Tested by |
Advanced Micro Devices |
| SPEC license # |
49 |
| Test location |
Austin, TX |
| Test date |
Oct 11, 2006 |
| H/w available |
Jul-2006 |
| JVM available |
Oct-2006 |
| OS available |
Mar-2005 |
| Other s/w available |
|
|
|
Tuning |
|---|
- BIOS
- Hardware Prefetcher : [Disabled]
- OS
- Using the local Security Settings console, "Lock pages in memory" was enabled for the user running the benchmark.
|
|
Notes |
|---|
| SUT requires a SuperMicro X7DBE motherboard (BIOS rev 1.1a), 8GB of PC2-5300 memory (8 x 1GB CL5 FBDIMMs), a Western Digital WD2500 SATA drive, a SSI EEB 3.51 specification compliant form-factor case, and a Zippy/Emacs 700 watt PSL-6701P Power Supply. |
|
