SPECjbb2005 SPECjbb2005 bops = 1972289, SPECjbb2005 bops/JVM = 123268
Hewlett-Packard Company ProLiant DL580 G7
IBM Corporation IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)

JVM run JVM Scores
1125323
2122845
3122028
4121301
5125749
6120835
7121693
8124694
9124025
10124359
11124153
12122516
13121954
14124658
15124143
16122013
SPECjbb2005 bops = 1972289, SPECjbb2005 bops/JVM = 123268

Hardware
Hardware Vendor Hewlett-Packard Company
Vendor URL http://www.hp.com
Model ProLiant DL580 G7
Processor Intel Xeon X7560 2.27 GHz (Intel Turbo Boost Technology up to 2.67 GHz)
MHz 2267
# of Chips 4
# of Cores 32
# of Cores/Chip 8
HW Threading Enabled? Yes
Procs Avail to Java 64
Memory (MB) 262144
Memory Details 64 x 4 GB PC3-10600R CL9
Primary cache 32 KB I + 32 KB D on chip, per core
Secondary cache 256 KB I+D on chip, per core
Other cache 24 MB I+D on chip, per chip
Filesystem NTFS
Disks 1 x 146 GB 15 K SAS
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)
JVM Command Line java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -spec.jbb.JBBmain -propfile SPECjbb.V1.props
JVM Initial Heap Memory (MB) 1875
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH c:\java\ibm\jre\bin\compressedrefs\jclSC160\vm.jar;
c:\java\ibm\jre\lib\annotation.jar;
c:\java\ibm\jre\lib\beans.jar;
c:\java\ibm\jre\lib\java.util.jar;
c:\java\ibm\jre\lib\jndi.jar;
c:\java\ibm\jre\lib\logging.jar;
c:\java\ibm\jre\lib\security.jar;
c:\java\ibm\jre\lib\sql.jar;
c:\java\ibm\jre\lib\ibmorb.jar;
c:\java\ibm\jre\lib\ibmorbapi.jar;
c:\java\ibm\jre\lib\ibmcfw.jar;
c:\java\ibm\jre\lib\rt.jar;
c:\java\ibm\jre\lib\charsets.jar;
c:\java\ibm\jre\lib\resources.jar;
c:\java\ibm\jre\lib\ibmpkcs.jar;
c:\java\ibm\jre\lib\ibmcertpathfw.jar;
c:\java\ibm\jre\lib\ibmjgssfw.jar;
c:\java\ibm\jre\lib\ibmjssefw.jar;
c:\java\ibm\jre\lib\ibmsaslfw.jar;
c:\java\ibm\jre\lib\ibmjcefw.jar;
c:\java\ibm\jre\lib\ibmjgssprovider.jar;
c:\java\ibm\jre\lib\ibmjsseprovider2.jar;
c:\java\ibm\jre\lib\ibmcertpathprovider.jar;
c:\java\ibm\jre\lib\ibmxmlcrypto.jar;
c:\java\ibm\jre\lib\management-agent.jar;
c:\java\ibm\jre\lib\xml.jar;
c:\java\ibm\jre\lib\jlm.jar;
c:\java\ibm\jre\lib\javascript.jar
OS Version Microsoft Windows Server 2008 Enterprise x64 Edition with R2
Other software
Test Information
Tested by Hewlett-Packard Company
SPEC license # 3
Test location Houston, TX
Test date Jun 16, 2010
H/w available Mar-2010
JVM available Jul-2009
OS available Nov-2009
Other s/w available
AOT Compilation

Tuning
"Lock pages in memory" enabled for benchmark user.
Power Option Set to High Performance
Used start /AFFINITY 0xF, 0xF0, 0xF00, 0xF000, 0xF0000, 0xF00000, 0xF000000, 0xF0000000, 0xF00000000, 0xF000000000, 0xF0000000000, 0xF00000000000, 0xF000000000000, 0xF0000000000000, 0xF00000000000000, 0xF000000000000000 was used to bind physical CPU nodes
Notes
Command line options are described at: http://publib.boulder.ibm.com/infocenter/javasdk/v6r0/index.jsp
BIOS Configuration
  • Power Regulator set to Static High
  • Node Interleaving Disabled
  • Hardware Prefetcher Disabled
  • Adjacent Sector Prefetcher Disabled


JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41364
2 98562
3 114217
4 125534 *
5 126057 *
6 126053 *
7 124794 *
8 124179 *
SPECjbb2005 (from 4 to 8) 125323 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41806
2 97279
3 114023
4 124426 *
5 123509 *
6 122280 *
7 122183 *
8 121828 *
SPECjbb2005 (from 4 to 8) 122845 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42092
2 100663
3 113511
4 123680 *
5 122673 *
6 122209 *
7 120996 *
8 120585 *
SPECjbb2005 (from 4 to 8) 122028 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40710
2 97354
3 110401
4 121919 *
5 122074 *
6 121259 *
7 120956 *
8 120299 *
SPECjbb2005 (from 4 to 8) 121301 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42313
2 97366
3 113583
4 127072 *
5 125694 *
6 125666 *
7 125357 *
8 124955 *
SPECjbb2005 (from 4 to 8) 125749 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41919
2 100234
3 112686
4 122052 *
5 121468 *
6 121011 *
7 119988 *
8 119655 *
SPECjbb2005 (from 4 to 8) 120835 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43546
2 98237
3 112204
4 123444 *
5 121841 *
6 121800 *
7 121234 *
8 120147 *
SPECjbb2005 (from 4 to 8) 121693 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41885
2 97936
3 111061
4 126511 *
5 125559 *
6 124402 *
7 123564 *
8 123436 *
SPECjbb2005 (from 4 to 8) 124694 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41782
2 98539
3 114977
4 125787 *
5 124246 *
6 123831 *
7 123317 *
8 122945 *
SPECjbb2005 (from 4 to 8) 124025 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41879
2 99539
3 113634
4 125720 *
5 124908 *
6 124158 *
7 123923 *
8 123089 *
SPECjbb2005 (from 4 to 8) 124359 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40997
2 98650
3 114116
4 124395 *
5 124871 *
6 124850 *
7 123387 *
8 123260 *
SPECjbb2005 (from 4 to 8) 124153 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43560
2 98433
3 114191
4 123852 *
5 123554 *
6 122625 *
7 121600 *
8 120947 *
SPECjbb2005 (from 4 to 8) 122516 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 44070
2 97696
3 113937
4 123263 *
5 122787 *
6 121855 *
7 121574 *
8 120288 *
SPECjbb2005 (from 4 to 8) 121954 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 42009
2 98176
3 111986
4 126278 *
5 125801 *
6 124610 *
7 123711 *
8 122892 *
SPECjbb2005 (from 4 to 8) 124658 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41059
2 99335
3 112821
4 126324 *
5 125007 *
6 123939 *
7 123297 *
8 122147 *
SPECjbb2005 (from 4 to 8) 124143 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010


JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40624
2 94292
3 110383
4 123357 *
5 122937 *
6 121670 *
7 121257 *
8 120843 *
SPECjbb2005 (from 4 to 8) 122013 SPECjbb2005 bops
SPEC license # 3 Tested by: Hewlett-Packard Company Test date: Jun 16, 2010

SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 19-Aug-2010
