| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems Inc. |
| Hardware Available | March 1998 |
| Software Available | May 1996 |
| Date Tested | February 1998 |
| SFS License Number | 6 |
| Licensee Locations | Palo Alto, CA |
| CPU, Memory and Power |
|---|
| Model Name | Sun Enterprise 6002 |
| Processor | 336 MHz UltraSPARC II |
| # of Processors | 18 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 4MB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 8 GB |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Solaris 2.5.1 |
| Other Software | N/A |
| File System | UFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 839 |
| Fileset Size | 246.0 GB |
|
| Network Subsystem |
|---|
| Network Type | 100Mbit Sun FastEthernet |
| Network Controller Desc. | SunSwift 100baseT f/w SCSI SBus Adapter |
| Number Networks | 9 (N1-N9) |
| Number Network Controllers | 9 |
| Protocol Type | UDP |
| Switch Type | 9 SunSwitch |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 13 |
| Number of Disks | 364 |
| Number of Filesystems | 360 (F1-F360) |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | On-board SCSI-2 |
| # of Controller Type | 1 |
| Number of Disks | 4 |
| Disk Type | 2GB 7200rpm |
| File Systems on Disks | OS, swap |
| Special Config Notes | |
| Disk Controller | FC SBUS Adapter (FC25/S)/FC Optical Module (FC25/OM) |
| # of Controller Type | 12 |
| Number of Disks | 360 |
| Disk Type | 2GB 7200rpm |
| File Systems on Disks | F1-30,F31-F60,F61-F90, F91-F120,F121-F150,F151-F180, F181-F210,F211-F240,F241-F270, F271-F300,F301-F330,F331-F360 |
| Special Config Notes | SPARCstorage Array 102 each w/ 30 drives |
|
| Testbed Configuration |
|---|
| LG # | LG Type | Network | Target File Systems | Notes |
| 1/2/3/4 | LG1 | N1 | F1,..,F331/F2,..,F332/F3,..,F333/F4,..,F334 | |
| 5/6/7 | LG1 | N2 | F5,..,F335/F6,..,F336/F7,..,F337 | |
| 8/9/10 | LG1 | N3 | F8,..,F338/F9,..,F339/F10,..,F340 | |
| 11/12/13/14 | LG1 | N4 | F11,..,F341/F12,..,F342/F13,..,F343/F14,..,F344 | |
| 15/16/17 | LG1 | N5 | F15,..,F345/F16,..,F346/F17,..,F347 | |
| 18/19/20 | LG1 | N6 | F18,..,F348/F19,..,F349/F20,..,F350 | |
| 21/22/23/24 | LG1 | N6 | F21,..,F351/F22,..,F352/F23,..,F353/F24,..,F354 | |
| 25/26/27 | LG1 | N6 | F25,..,F355/F26,..,F356/F27,..,F357 | |
| 28/29/30 | LG1 | N6 | F28,..,F358/F29,..,F359/F30,..,F360 | |
