NEC Corporation Express5800/R120b-2 ssj_ops@100% = 908,306
ssj_ops@100% per JVM = 75,692
Test Sponsor: NEC Corporation SPEC License #: 9006 Test Method: Single Node
Tested By: NEC Corporation Test Location: Fuchu, Tokyo, Japan Test Date: Feb 2, 2011
Hardware Availability: Feb-2011 Software Availability: Sep-2010 Publication: Feb 24, 2011
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     896,381
Calibration 2     913,343
Calibration 3     912,271
ssj_ops@calibrated=912,807
100% 99.5% 912,807 908,306
90% 90.2% 821,526 823,170
80% 80.1% 730,246 730,729
70% 70.1% 638,965 639,716
60% 59.8% 547,684 545,826
50% 50.0% 456,404 456,690
40% 40.0% 365,123 364,752
30% 29.9% 273,842 273,188
20% 20.0% 182,561 182,940
10% 10.0% 91,281 91,052
Active Idle   0 0
Graph of results
System Under Test
Set: 'sut'
Set Identifier: sut
Set Description: Express5800/R120b-2 (Intel Xeon X5675, 3.06 GHz)
# of Identical Nodes: 1
Comment: None
Hardware
Hardware Vendor: NEC Corporation
Model: Express5800/R120b-2
Form Factor: 2U
CPU Name: Intel Xeon X5675
CPU Characteristics: Hexa-Core, 3.06 GHz, 12 MB L3 Cache
CPU Frequency (MHz): 3066
CPU(s) Enabled: 12 cores, 2 chips, 6 cores/chip
Hardware Threads: 24 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 256 KB I+D on chip per core
Tertiary Cache: 12 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 24
# and size of DIMM: 6 x 4096 MB
Memory Details: 4GB 2Rx4 PC3L-10600R ECC CL9; slots CPU1_DIMM1, CPU1_DIMM2, CPU1_DIMM3, CPU2_DIMM1, CPU2_DIMM2 and CPU2_DIMM3 populated
Power Supply Quantity and Rating (W): 1 x 750
Power Supply Details: Delta DPS-750VB A
Disk Drive: 1 x 50GB SSD SATA, NEC P/N:N8150-702
Disk Controller: Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x Integrated Intel 82576 Gigabit Dual Port Ethernet Controller
NICs Enabled in Firmware / OS / Connected: 2/1/1
Network Speed (Mbit): 1000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Power saver
Operating System (OS): Microsoft Windows Server 2008 Enterprise x64 Edition
OS Version: SP2
Filesystem: NTFS
JVM Vendor: Oracle Corporation
JVM Version: Oracle Java HotSpot(TM) 64-Bit Server VM on Windows, version 1.6.0_21 Performance Release
JVM Command-line Options: -Xms1650m -Xmx1650m -Xmn1450m -XX:+AggressiveOpts -XX:+UseBiasedLocking -XX:+UseStringCache -XX:+OptimizeStringConcat -XX:+UseCompressedStrings -XX:+UseParallelOldGC -XX:ParallelGCThreads=2 -XX:+UseLargePages -XX:LargePageSizeInBytes=2m -XX:+UseCompressedOops -XX:+AlwaysPreTouch -XX:AllocatePrefetchDistance=192 -XX:AllocatePrefetchLines=4 -XX:SurvivorRatio=50 -XX:TargetSurvivorRatio=90 -XX:InlineSmallCode=5500 -XX:MaxInlineSize=220 -XX:FreqInlineSize=2500 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15
JVM Affinity: start /affinity [3,C,30,C0,300,C00,3000,C000,30000,C0000,300000,C00000]
JVM Instances: 12
JVM Initial Heap (MB): 1650
JVM Maximum Heap (MB): 1650
JVM Address Bits: 64
Boot Firmware Version: 4.6.2C18
Management Firmware Version: 1.28
Workload Version: SSJ 1.2.6
Director Location: Controller
Other Software: None
Boot Firmware Settings
Management Firmware Settings
None
System Under Test Notes
Notes
JVM Instance Summary
JVM Instance ssj_ops@100%
R120b-2.001 72,779
R120b-2.002 74,922
R120b-2.003 76,982
R120b-2.004 75,732
R120b-2.005 77,991
R120b-2.006 77,981
R120b-2.007 77,422
R120b-2.008 71,650
R120b-2.009 76,244
R120b-2.010 77,831
R120b-2.011 78,553
R120b-2.012 70,218
ssj_ops@100% 908,306
ssj_ops@100% per JVM 75,692
Graph of per-instance results
JVM 'R120b-2.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     71,087
Calibration 2     72,249
Calibration 3     72,430
ssj_ops@calibrated=72,339
100% 100.6% 72,339 72,779
90% 91.2% 65,105 65,974
80% 80.4% 57,872 58,147
70% 70.8% 50,638 51,243
60% 59.3% 43,404 42,920
50% 50.2% 36,170 36,331
40% 40.4% 28,936 29,258
30% 29.6% 21,702 21,433
20% 20.0% 14,468 14,466
10% 10.3% 7,234 7,425
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     75,614
Calibration 2     76,102
Calibration 3     74,993
ssj_ops@calibrated=75,548
100% 99.2% 75,548 74,922
90% 91.4% 67,993 69,056
80% 81.5% 60,438 61,589
70% 70.2% 52,883 53,032
60% 60.2% 45,329 45,476
50% 49.5% 37,774 37,369
40% 39.2% 30,219 29,608
30% 29.9% 22,664 22,618
20% 20.4% 15,110 15,383
10% 10.1% 7,555 7,602
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     76,421
Calibration 2     77,045
Calibration 3     77,168
ssj_ops@calibrated=77,106
100% 99.8% 77,106 76,982
90% 89.0% 69,396 68,636
80% 79.2% 61,685 61,056
70% 69.9% 53,975 53,920
60% 60.1% 46,264 46,353
50% 50.3% 38,553 38,823
40% 39.5% 30,843 30,466
30% 30.2% 23,132 23,279
20% 20.2% 15,421 15,546
10% 10.1% 7,711 7,779
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     75,684
Calibration 2     76,659
Calibration 3     76,671
ssj_ops@calibrated=76,665
100% 98.8% 76,665 75,732
90% 89.4% 68,998 68,546
80% 81.5% 61,332 62,487
70% 69.9% 53,665 53,586
60% 60.0% 45,999 45,990
50% 49.6% 38,332 38,020
40% 40.3% 30,666 30,865
30% 30.7% 22,999 23,521
20% 20.2% 15,333 15,496
10% 10.4% 7,666 7,958
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     76,599
Calibration 2     78,382
Calibration 3     78,408
ssj_ops@calibrated=78,395
100% 99.5% 78,395 77,991
90% 89.4% 70,555 70,057
80% 80.3% 62,716 62,912
70% 70.7% 54,876 55,394
60% 59.6% 47,037 46,752
50% 49.9% 39,197 39,117
40% 40.3% 31,358 31,557
30% 29.7% 23,518 23,304
20% 19.7% 15,679 15,429
10% 10.0% 7,839 7,872
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     77,528
Calibration 2     78,641
Calibration 3     78,512
ssj_ops@calibrated=78,577
100% 99.2% 78,577 77,981
90% 91.2% 70,719 71,663
80% 79.9% 62,861 62,747
70% 70.2% 55,004 55,141
60% 60.3% 47,146 47,396
50% 49.8% 39,288 39,120
40% 39.3% 31,431 30,878
30% 29.7% 23,573 23,349
20% 20.1% 15,715 15,766
10% 9.8% 7,858 7,679
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.007' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     75,937
Calibration 2     77,923
Calibration 3     77,776
ssj_ops@calibrated=77,849
100% 99.5% 77,849 77,422
90% 89.5% 70,064 69,678
80% 79.7% 62,279 62,045
70% 69.4% 54,495 54,001
60% 59.5% 46,710 46,319
50% 51.2% 38,925 39,861
40% 39.6% 31,140 30,824
30% 29.5% 23,355 22,979
20% 20.2% 15,570 15,727
10% 10.0% 7,785 7,779
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.008' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     69,378
Calibration 2     71,411
Calibration 3     71,491
ssj_ops@calibrated=71,451
100% 100.3% 71,451 71,650
90% 90.6% 64,306 64,717
80% 80.6% 57,161 57,581
70% 70.6% 50,016 50,433
60% 59.8% 42,871 42,744
50% 49.7% 35,725 35,529
40% 40.3% 28,580 28,791
30% 30.0% 21,435 21,449
20% 19.3% 14,290 13,787
10% 9.9% 7,145 7,071
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.009' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     75,544
Calibration 2     76,896
Calibration 3     76,703
ssj_ops@calibrated=76,799
100% 99.3% 76,799 76,244
90% 90.5% 69,119 69,495
80% 78.0% 61,439 59,897
70% 69.5% 53,759 53,390
60% 59.9% 46,080 45,994
50% 49.4% 38,400 37,958
40% 40.1% 30,720 30,835
30% 29.8% 23,040 22,885
20% 19.9% 15,360 15,287
10% 9.7% 7,680 7,484
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.010' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     76,049
Calibration 2     77,405
Calibration 3     77,558
ssj_ops@calibrated=77,482
100% 100.5% 77,482 77,831
90% 90.9% 69,734 70,444
80% 79.3% 61,985 61,466
70% 71.0% 54,237 54,974
60% 59.2% 46,489 45,845
50% 50.5% 38,741 39,114
40% 40.4% 30,993 31,294
30% 30.3% 23,245 23,479
20% 20.6% 15,496 15,929
10% 9.6% 7,748 7,417
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.011' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     76,779
Calibration 2     78,778
Calibration 3     78,583
ssj_ops@calibrated=78,680
100% 99.8% 78,680 78,553
90% 88.4% 70,812 69,567
80% 80.6% 62,944 63,378
70% 68.0% 55,076 53,466
60% 59.9% 47,208 47,111
50% 49.7% 39,340 39,118
40% 40.2% 31,472 31,633
30% 29.7% 23,604 23,383
20% 19.8% 15,736 15,546
10% 10.0% 7,868 7,883
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'R120b-2.012' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     69,761
Calibration 2     71,852
Calibration 3     71,979
ssj_ops@calibrated=71,916
100% 97.6% 71,916 70,218
90% 90.9% 64,724 65,336
80% 79.8% 57,533 57,424
70% 71.1% 50,341 51,137
60% 59.7% 43,150 42,925
50% 50.5% 35,958 36,329
40% 40.0% 28,766 28,743
30% 29.9% 21,575 21,511
20% 20.3% 14,383 14,577
10% 9.9% 7,192 7,104
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
