| Server Configuration and Availability |
|---|
| Vendor | Traakan, Inc. |
| Hardware Available | February 2002 |
| Software Available | February 2002 |
| Date Tested | February 2002 |
| SFS License Number | 1730 |
| Licensee Locations | Los Altos, CA |
| CPU, Memory and Power |
|---|
| Model Name | RainFiler (1-Node,32x36,UDP) |
| Processor | Compaq Proliant DL380, 1.266GHz PIII |
| # of Processors | 1 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 512KB(I+D) on chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 4 GB |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Fastraak 1.19 |
| Other Software | N/A |
| File System | Fastraak SFS2 |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 400 |
| Fileset Size | 151.6 GB |
|
| Network Subsystem |
|---|
| Network Type | 100BASE-T Ethernet, all Intel 82559 |
| Network Controller Desc. | 2 Integrated + 2 on Compaq NC3134 NIC |
| Number Networks | 4 (N1-N4) |
| Number Network Controllers | 4 |
| Protocol Type | UDP |
| Switch Type | 4 Hewlett Packard ProCurve 4000M |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 32 |
| Number of Filesystems | 8 plus HOST OS File System |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | Mylex E2000 with 64MB cache+BBU |
| # of Controller Type | 2 |
| Number of Disks | 16 per Controller |
| Disk Type | Quantum Atlas 10KII (3.5 Series) LVD |
| File Systems on Disks | F1-F8, 1 FS on each 4 Drive Raid0 Set |
| Special Config Notes | F9 (200MB OS) beginning of first Raid0 Set |
|
