| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | January 2004 |
| Software Available | April 2004 |
| Date Tested | May 2004 |
| SFS License Number | 33 |
| Licensee Locations | Sunnyvale, CA |
| CPU, Memory and Power |
|---|
| Model Name | FAS270c Failover Cluster |
| Processor | 650-MHz Broadcom BCM1250 |
| # of Processors | 4 cores, 2 chips, 2 cores/chip |
| Primary Cache | 32 KB I + 32 KB D on chip |
| Secondary Cache | 512 KB on-chip |
| Other Cache | N/A |
| UPS | none |
| Other Hardware | -- |
| Memory Size | 2048 MB (1024 MB per node) |
| NVRAM Size | 256 MB (128 MB per node) |
| NVRAM Type | battery backed up DIMM on main memory card |
| NVRAM Description | minimum 3-day battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 6.5.1 |
| Other Software | Cluster Option |
| File System | WAFL |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | default |
| # NFS Processes | N/A |
| Fileset Size | 129.6 GB |
|
| Network Subsystem |
|---|
| Network Type | Jumbo Frame Gigabit Ethernet |
| Network Controller Desc. | Broadcom BCM1250 on-chip Gigabit Ethernet controller |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 (1 per node) |
| Protocol Type | TCP |
| Switch Type | Extreme BlackDiamond 6816 (N1) |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 42 |
| Number of Filesystems | 2 |
| File System Creation Ops | default |
| File System Config | 2 RAID-DP (Double Parity) groups of 10 disks each. |
| Disk Controller | onboard QLogic ISP 2312 FC Controller (256 KB RAM standard) |
| # of Controller Type | 2 |
| Number of Disks | 21/21 |
| Disk Type | X273A 72GB 15K RPM FC-AL |
| File Systems on Disks | F1/F2 |
| Special Config Notes | see notes |
|
