| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems, Inc. |
| Hardware Available | September 2004 |
| Software Available | September 2004 |
| Date Tested | September 2004 |
| SFS License Number | 6 |
| Licensee Locations | Santa Clara, CA |
| CPU, Memory and Power |
|---|
| Model Name | StorEdge 5210 NAS |
| Processor | 3.06GHz Intel Xeon |
| # of Processors | 1 core, 1 chip, 1 core/chip |
| Primary Cache | 12K micro-ops I + 8KBD on chip |
| Secondary Cache | 512KB (I+D) on chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 4 GB |
| NVRAM Size | 256 MB (128 MB per LSI MegaRAID controller) |
| NVRAM Type | MegaRAID controller cache |
| NVRAM Description | write-back with battery backup |
| Server Software |
|---|
| OS Name and Version | NetFORCE Ver.4.2.39 Build 160 |
| Other Software | N/A |
| File System | sfs2 |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Default |
| # NFS Processes | 60 |
| Fileset Size | 116.0 GB |
|
| Network Subsystem |
|---|
| Network Type | on-board 10/100/1000-Mbps BaseT |
| Network Controller Desc. | Gigabit Ethernet |
| Number Networks | 2 (N1,N2) |
| Number Network Controllers | 2 |
| Protocol Type | TCP |
| Switch Type | Asante GX5-2400 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 42 |
| Number of Filesystems | 13 (F1-F13) |
| File System Creation Ops | default |
| File System Config | (1) 256GB file system per 3-disk RAID5 LUN |
| Disk Controller | LSI Logic MegaRAID Dual Channel Ultra 320 SCSI |
| # of Controller Type | 2 |
| Number of Disks | 42 |
| Disk Type | Hitachi Model DK32EJ-14NC 146GB 10K rpm |
| File Systems on Disks | F1-F13 |
| Special Config Notes | 13 file systems on 13 RAID 5 LUNs of 2+1 spindles each |
|
