| Name | Supermicro A+ AS-1115CS-TNR |
| Vendor | Super Micro Computer, Inc |
| Vendor URL | https://www.supermicro.com |
| Available | Nov-2022 |
| Model | H13SSW |
| Form Factor | 1U |
| CPU Name | AMD EPYC 9654 |
| CPU Characteristics | 96 core, 2.4GHz, 384MB L3 Cache (Max. Boost Clock up to 3.7GHz) |
| Number of Systems | 1 |
| Nodes Per System | 1 |
| Chips Per System | 1 |
| Cores Per System | 96 |
| Cores Per Chip | 96 |
| Threads Per System | 192 |
| Threads Per Core | 2 |
| Version | 0.10 09/13/2022 |
| CPU Frequency (MHz) | 2400 |
| Primary Cache | 32KB(I)+32KB(D) per core |
| Secondary Cache | 1MB (I+D) per core |
| Tertiary Cache | 384MB (I+D) on chip per chip |
| Other Cache | None |
| Disk | 10 x 1.92 TB NVMe PCIe Gen4.0 |
| File System | btrfs |
| Memory Amount (GB) | 768 |
| # and size of DIMM(s) | 12 x 64GB |
| Memory Details | 64GB 2Rx4 PC5-38400R , running @ 4800 MHz |
| # and type of Network Interface Cards (NICs) | 1 x 1 GbE NIC |
| Power Supply Quantity and Rating (W) | 2 x 860w |
| Other Hardware | None |
| Cabinet/Housing/Enclosure | None |
| Shared Description | None |
| Shared Comment | None |
| Notes | - NA: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.
|
|
| Name | None |
| Vendor | None |
| Vendor URL | None |
| Version | None |
| Available | None |
| Bitness | None |
| Notes | None |
|
|
