SPEC® MPIM2007 Result

Copyright 2006-2010 Standard Performance Evaluation Corporation

Huawei

Huawei 2488H V5

SPECmpiM_peak2007 = Not Run

MPI2007 license: 27 Test date: Jun-2017
Test sponsor: Huawei Hardware Availability: Jul-2017
Tested by: Huawei Software Availability: Apr-2017
Benchmark results graph

Results Table

Benchmark Base Peak
Ranks Seconds Ratio Seconds Ratio Seconds Ratio Ranks Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
104.milc 112 74.3 21.1 74.3 21.1 74.5 21.0
107.leslie3d 112 186   28.1 185   28.2 185   28.2
113.GemsFDTD 112 157   40.3 157   40.2 157   40.1
115.fds4 112 74.4 26.2 74.3 26.3 74.2 26.3
121.pop2 112 121   34.1 121   34.3 121   34.1
122.tachyon 112 86.1 32.5 86.3 32.4 85.5 32.7
126.lammps 112 103   28.2 104   28.2 104   28.1
127.wrf2 112 138   56.7 138   56.6 137   57.0
128.GAPgeofem 112 47.7 43.2 47.5 43.5 47.5 43.5
129.tera_tf 112 99.4 27.9 99.4 27.9 99.6 27.8
130.socorro 112 59.2 64.4 58.7 65.0 59.1 64.5
132.zeusmp2 112 81.3 38.2 81.3 38.2 81.3 38.2
137.lu 112 76.8 47.9 76.7 48.0 76.9 47.8
Hardware Summary
Type of System: Homogeneous
Compute Node: 2488H V5 Node
File Server Node: 2488H V5 Node
Head Node: 2488H V5 Node
Total Compute Nodes: 1
Total Chips: 4
Total Cores: 112
Total Threads: 112
Total Memory: 768 GB
Base Ranks Run: 112
Minimum Peak Ranks: --
Maximum Peak Ranks: --
Software Summary
C Compiler: Intel C++ Composer XE 2017 for Linux,
Version 17.0.4.196 Build 20170411
C++ Compiler: Intel C++ Composer XE 2017 for Linux,
Version 17.0.4.196 Build 20170411
Fortran Compiler: Intel Fortran Composer XE 2017 for Linux,
Version 17.0.4.196 Build 20170411
Base Pointers: 64-bit
Peak Pointers: 64-bit
MPI Library: Intel MPI Library for Linux,
Version 2017 Update 3 Build 20170405
Other MPI Info: None
Pre-processors: No
Other Software: None

Node Description: 2488H V5 Node

Hardware
Number of nodes: 1
Uses of the node: head, compute, fileserver
Vendor: Huawei
Model: Huawei 2488H V5
CPU Name: Intel Xeon Platinum 8180 CPU
CPU(s) orderable: 2, 4 chip
Chips enabled: 4
Cores enabled: 112
Cores per chip: 28
Threads per core: 1
CPU Characteristics: Intel Turbo Boost Technology on,
Hyper-Threading Technology (SMT) disable
CPU MHz: 2500
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 1 MB I+D on chip per core
L3 Cache: 38.5 MB I+D on chip per chip
Other Cache: None
Memory: 768 GB (24 x 32 GB 2Rx4 PC4-2666V, running at
2666 MHz)
Disk Subsystem: 2 x 600 GB 10K RPM SAS
Other Hardware: None
Adapter: 0
Number of Adapters: 0
Slot Type: 0
Data Rate: 0
Ports Used: 0
Interconnect Type: 0
Software
Adapter: 0
Adapter Driver: 0
Adapter Firmware: --
Operating System: Red Hat Enterprise Linux Server 7.3
(Maipo)
Linux kernel 3.10.0-514.el7.x86_64
Local File System: xfs
Shared File System: None
System State: Multi-User
Other Software: None

Submit Notes

The config file option 'submit' was used.

General Notes

 MPI startup command:
   mpiexec.hydra command was used to start MPI jobs.

 BIOS settings:
   Intel Hyper-Threading Technology (SMT):Disable
   Intel Turbo Boost Technology (Turbo):Enabled (default is Enabled)

Base Compiler Invocation

C benchmarks:

 mpiicc

C++ benchmarks:

126.lammps:  mpiicpc

Fortran benchmarks:

 mpiifort

Benchmarks using both Fortran and C:

 mpiicc   mpiifort

Base Portability Flags

121.pop2:  -DSPEC_MPI_CASE_FLAG
126.lammps:  -DMPICH_IGNORE_CXX_SEEK
127.wrf2:  -DSPEC_MPI_CASE_FLAG   -DSPEC_MPI_LINUX

Base Optimization Flags

C benchmarks:

 -O3   -xCORE-AVX2   -no-prec-div

C++ benchmarks:

126.lammps:  -O3   -xCORE-AVX2   -no-prec-div

Fortran benchmarks:

 -O3   -xCORE-AVX2   -no-prec-div

Benchmarks using both Fortran and C:

 -O3   -xCORE-AVX2   -no-prec-div

The flags file that was used to format this result can be browsed at
http://www.spec.org/mpi2007/flags/Huawei_x86_64_Intel_linux.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/mpi2007/flags/Huawei_x86_64_Intel_linux.xml.
