Hewlett Packard Enterprise Synergy 480 Gen10 Compute Module SPECpower_ssj2008 = 10,552 overall ssj_ops/watt
Test Sponsor: Hewlett Packard Enterprise SPEC License #: 3 Test Method: Multi Node
Tested By: Hewlett Packard Enterprise Test Location: Houston, TX, USA Test Date: Mar 12, 2019
Hardware Availability: Apr-2019 Software Availability: Mar-2019 Publication: Apr 2, 2019
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Average Active Power (W) Minimum Ambient Temperature (°C)
Calibration 1 2,491 22.7
Calibration 2 2,499 22.8
Calibration 3 2,505 22.7
100% 2,494 22.8
90% 2,265 22.8
80% 1,985 22.8
70% 1,701 22.8
60% 1,499 22.8
50% 1,323 22.8
40% 1,162 22.8
30% 1,009 22.8
20% 868 22.8
10% 742 22.8
Active Idle 425 22.8
Graph of power and temperature
Measurement Devices
Power Analyzer pwr1
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB53024
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-80-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supply 5
Power Analyzer pwr2
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB47168
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-60-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supply 3
Power Analyzer pwr3
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GC21887
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-20-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supplies 1 and 2
Temperature Sensor temp1
Hardware Vendor: Digi International Inc.
Model: Watchport/H
Driver Version: 5.70.105.0
Connectivity: USB
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
Setup Description: 5 mm in front of SUT main intake
Notes
None
Power Details for Device pwr1
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 2.91 5.0 0.986 618 0.4%
Calibration 2 216 300.0 2.92 5.0 0.986 620 0.4%
Calibration 3 215 300.0 2.92 5.0 0.986 621 0.4%
100% 215 300.0 2.91 5.0 0.986 618 0.4%
90% 216 300.0 2.65 5.0 0.983 561 0.5%
80% 216 300.0 2.30 5.0 0.978 486 0.5%
70% 216 300.0 1.91 5.0 0.967 398 0.6%
60% 216 300.0 1.64 5.0 0.956 338 0.7%
50% 216 300.0 1.41 5.0 0.940 285 0.7%
40% 216 300.0 1.18 5.0 0.881 225 0.9%
30% 216 300.0 1.06 2.0 0.862 197 0.6%
20% 216 300.0 1.01 2.0 0.854 186 0.6%
10% 216 300.0 0.938 2.0 0.825 167 0.6%
Active Idle 216 300.0 0.585 1.0 0.632 80.1 0.8%
Power details for pwr1
Power Details for Device pwr2
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 5.98 10.0 0.990 1,270 0.4%
Calibration 2 215 300.0 5.99 10.0 0.990 1,274 0.4%
Calibration 3 215 300.0 6.01 10.0 0.990 1,277 0.4%
100% 215 300.0 5.99 10.0 0.990 1,272 0.4%
90% 215 300.0 5.46 10.0 0.988 1,158 0.4%
80% 215 300.0 4.82 10.0 0.984 1,019 0.5%
70% 215 300.0 4.22 10.0 0.979 889 0.5%
60% 215 300.0 3.78 10.0 0.973 792 0.6%
50% 215 300.0 3.38 5.0 0.966 704 0.4%
40% 215 300.0 3.09 5.0 0.958 638 0.4%
30% 216 300.0 2.78 5.0 0.948 568 0.5%
20% 216 300.0 2.47 5.0 0.920 490 0.5%
10% 216 300.0 2.07 5.0 0.890 398 0.6%
Active Idle 216 300.0 1.43 2.0 0.794 245 0.5%
Power details for pwr2
Power Details for Device pwr3
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 213 300.0 2.88 5.0 0.984 603 0.4%
Calibration 2 213 300.0 2.89 5.0 0.984 605 0.4%
Calibration 3 213 300.0 2.90 5.0 0.984 607 0.4%
100% 213 300.0 2.89 5.0 0.984 604 0.4%
90% 213 300.0 2.62 5.0 0.980 546 0.5%
80% 213 300.0 2.31 5.0 0.975 479 0.5%
70% 213 300.0 2.01 5.0 0.966 414 0.6%
60% 213 300.0 1.81 5.0 0.959 369 0.6%
50% 213 300.0 1.64 5.0 0.951 333 0.7%
40% 213 300.0 1.49 5.0 0.940 298 0.7%
30% 213 300.0 1.25 2.0 0.913 243 0.5%
20% 213 300.0 1.06 2.0 0.850 193 0.6%
10% 213 300.0 0.996 2.0 0.833 177 0.6%
Active Idle 213 300.0 0.663 1.0 0.709 100 0.6%
Power details for pwr3
