SPECpower_ssj2008 Aggregate Performance Report

SPECpower_ssj2008

Aggregate Performance Report

Nokia Corporation AE-SER1U-A			ssj_ops@100% = 7,411,713 ssj_ops@100% per Host = 1,482,343 ssj_ops@100% per JVM = 74,117
Test Sponsor:	Nokia Corporation	SPEC License #:	6037	Test Method:	Multi Node
Tested By:	Nokia Corporation	Test Location:	HangZhou, Zhejiang, China	Test Date:	Dec 23, 2019
Hardware Availability:	Dec-2019	Software Availability:	Dec-2019	Publication:	Feb 14, 2020
System Source:	Single Supplier	System Designation:	Server	Power Provisioning:	Line-powered

# of Nodes	# of Chips	# of Cores	# of Threads	Total RAM (GB)	# of OS Images	# of JVM Instances
5	5	100	200	320	5	100

Shared Hardware
Enclosure:	Nokia AirFrame Open Edge
Form Factor:	3U
Power Supply Quantity and Rating (W):	1 x 2000
Power Supply Details:	AE-PSUAC-A, AF 2kW AC PSU for OE chassis (F to R)
Network Switch:	AE-Z9100ON-A+G85
Network Switch Details:	AirFrame OE Switch Z9100ON 32xPlug 100Gb
KVM Switch:	None
KVM Switch Details:	N/A
Other Hardware:	None
Comment:	Network switch did not measure for Power

Hardware per Node
Hardware Vendor:	Nokia Corporation
Model:	AE-SER1U-A
Form Factor:	3U
CPU Name:	Intel(R) Xeon(R) Gold 6210U CPU @ 2.50GHz
CPU Characteristics:	20 Core, 2.5GHz, 27.5MB L3 Cache
CPU Frequency (MHz):	2500
CPU(s) Enabled:	20 cores, 1 chip, 20 cores/chip
Hardware Threads:	40 (2 / core)
CPU(s) Orderable:	1 chip
Primary Cache:	32 KB I + 32 KB D on chip per core
Secondary Cache:	1 MB I+D on chip per core
Tertiary Cache:	28160 KB I+D on chip per chip
Other Cache:	None
Memory Amount (GB):	64
# and size of DIMM:	4 x 16 GB
Memory Details:	4 x 16 GB 2Rx4 PC4-2933Y-RB2-12-DC1; slots 0,1,4 and 5 populated
Power Supply Quantity and Rating (W):	None
Power Supply Details:	Shared
Disk Drive:	1 x M.2 SSD 480G, Intel S4510 P/N: SSDSCKJB480G7
Disk Controller:	Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed:	1 x Intel Corporation I210 Gigabit Network Connection(onboard)
NICs Enabled in Firmware / OS / Connected:	1/1/1
Network Speed (Mbit):	1000
Keyboard:	None
Mouse:	None
Monitor:	None
Optical Drives:	No
Other Hardware:	None

Software per Node
Power Management:	Enabled (see SUT Notes)
Operating System (OS):	CentOS Linux release 8.0.1905 (Core)
OS Version:	Kernel 4.18.0-80.el8.x86_64
Filesystem:	EXT4
JVM Vendor:	Oracle Corporation
JVM Version:	OpenJDK 64-Bit Server VM (build 25.181-b13, mixed mode),1.8.0_181
JVM Command-line Options:	-Djava.awt.headless=true -server -Xms1300m -Xmx1300m -Xmn1100m -XX:SurvivorRatio=1 -XX:TargetSurvivorRatio=99 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:ParallelGCThreads=2 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+AggressiveOpts -XX:+UseLargePages -XX:+UseParallelOldGC
JVM Affinity:	None
JVM Instances:	20
JVM Initial Heap (MB):	1300
JVM Maximum Heap (MB):	1300
JVM Address Bits:	64
Boot Firmware Version:	3B17(Oct-2019)
Management Firmware Version:	3.42.00(Nov-2019)
Workload Version:	SSJ 1.2.10
Director Location:	Controller
Other Software:	None

See SUT Notes

Benchmark started via ssh.
N/A: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.

None

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

SPECpower_ssj2008 Reporter Version: [SSJ 1.2.10, May 9, 2012]
