Hewlett Packard Enterprise Synergy 480 Gen10 Plus Compute Module ssj_ops@100% = 8,360,150
ssj_ops@100% per JVM = 104,502
Test Sponsor: Hewlett Packard Enterprise SPEC License #: 3 Test Method: Multi Node
Tested By: Hewlett Packard Enterprise Test Location: Houston, TX, USA Test Date: Jan 11, 2022
Hardware Availability: Apr-2021 Software Availability: Apr-2021 Publication: Feb 16, 2022
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     6,754,665
Calibration 2     8,387,063
Calibration 3     8,391,294
ssj_ops@calibrated=8,389,178
100% 99.7% 8,389,178 8,360,150
90% 89.9% 7,550,260 7,540,517
80% 80.0% 6,711,343 6,710,093
70% 70.1% 5,872,425 5,877,831
60% 59.9% 5,033,507 5,028,143
50% 50.0% 4,194,589 4,192,985
40% 40.0% 3,355,671 3,356,365
30% 30.1% 2,516,753 2,521,472
20% 20.0% 1,677,836 1,675,420
10% 10.0% 838,918 836,291
Active Idle   0 0
Graph of results
System Under Test
Set: 'SUT'
Set Identifier: SUT
Set Description: System Under Test
# of Identical Nodes: 10
Comment: SUT
Hardware
Hardware Vendor: Hewlett Packard Enterprise
Model: Synergy 480 Gen10 Plus Compute Module
Form Factor: Blade
CPU Name: Intel Xeon Platinum 8380 CPU @ 2.30GHz
CPU Characteristics: 40-Core, 2.30 GHz, 60MB L3 Cache
CPU Frequency (MHz): 2300
CPU(s) Enabled: 80 cores, 2 chips, 40 cores/chip
Hardware Threads: 160 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 48 KB D on chip per core
Secondary Cache: 1280 KB I+D on chip per core
Tertiary Cache: 60 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 256
# and size of DIMM: 16 x 16384 MB
Memory Details: 16 x 16GB 2Rx8 PC4-3200-T; slots 1, 3, 5, 7, 10, 12, 14 & 16 on each socket
Power Supply Quantity and Rating (W): None
Power Supply Details: Shared
Disk Drive: HPE 240GB SATA 6G Read Intensive SFF (P18420-B21)
Disk Controller: Embedded SATA Controller
# and type of Network Interface Cards (NICs) Installed: 1 x HPE Synergy 4820C 10/20/25Gb CNA
NICs Enabled in Firmware / OS / Connected: 2/1/1
Network Speed (Mbit): 10000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Enabled (see SUT Notes)
Operating System (OS): SUSE Linux Enterprise Server 15 SP2
OS Version: 5.3.18-22-default
Filesystem: xfs
JVM Vendor: Oracle Corporation
JVM Version: Oracle Java HotSpot(TM) 64-Bit Server VM 18.9 (build 11.0.11+9-LTS-194, mixed mode)
JVM Command-line Options: -server -Xmn1700m -Xms1950m -Xmx1950m -XX:SurvivorRatio=1 -XX:TargetSurvivorRatio=99 -XX:ParallelGCThreads=2 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParallelOldGC -XX:UseAVX=0 -XX:-UseAdaptiveSizePolicy -XX:-ThreadLocalHandshakes
JVM Affinity: for each physicalCore { numactl -C physicalCoreId, physicalCoreId + 80 }
JVM Instances: 80
JVM Initial Heap (MB): 1950
JVM Maximum Heap (MB): 1950
JVM Address Bits: 64
Boot Firmware Version: I44 v1.40 (03/05/2021)
Management Firmware Version: 2.40 pass 31 Jan 05 2021
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: None
Boot Firmware Settings
BIOS Platform Configuration (RBSU):
Management Firmware Settings
See SUT Notes
System Under Test Notes
Notes
None
JVM Instance Summary
JVM Instance ssj_ops@100%
sy480-05.001 106,996
sy480-05.002 95,972
sy480-05.003 101,753
sy480-05.004 105,624
sy480-05.005 104,738
sy480-05.006 107,696
sy480-05.007 106,456
sy480-05.008 106,990
sy480-05.009 107,699
sy480-05.010 103,354
sy480-05.011 103,402
sy480-05.012 105,714
sy480-05.013 99,258
sy480-05.014 104,189
sy480-05.015 104,913
sy480-05.016 102,803
sy480-05.017 103,845
sy480-05.018 105,647
sy480-05.019 100,274
sy480-05.020 98,843
sy480-05.021 106,581
sy480-05.022 106,770
sy480-05.023 104,137
sy480-05.024 101,029
sy480-05.025 103,311
sy480-05.026 106,852
sy480-05.027 101,484
sy480-05.028 105,801
sy480-05.029 107,073
sy480-05.030 106,521
sy480-05.031 103,157
sy480-05.032 105,736
sy480-05.033 106,546
sy480-05.034 105,093
sy480-05.035 104,588
sy480-05.036 102,830
sy480-05.037 105,369
sy480-05.038 104,747
sy480-05.039 106,346
sy480-05.040 104,829
sy480-05.041 105,482
sy480-05.042 104,993
sy480-05.043 97,418
sy480-05.044 106,111
sy480-05.045 105,981
sy480-05.046 106,804
sy480-05.047 105,147
sy480-05.048 106,796
sy480-05.049 106,802
sy480-05.050 105,004
sy480-05.051 105,718
sy480-05.052 104,207
sy480-05.053 105,222
sy480-05.054 104,766
sy480-05.055 103,438
sy480-05.056 106,049
sy480-05.057 104,255
sy480-05.058 106,664
sy480-05.059 103,189
sy480-05.060 103,476
sy480-05.061 105,187
sy480-05.062 97,905
sy480-05.063 103,910
sy480-05.064 104,592
sy480-05.065 103,915
sy480-05.066 105,452
sy480-05.067 103,546
sy480-05.068 105,605
sy480-05.069 104,815
sy480-05.070 102,401
sy480-05.071 109,095
sy480-05.072 106,454
sy480-05.073 106,802
sy480-05.074 106,166
sy480-05.075 100,382
sy480-05.076 105,884
sy480-05.077 105,786
sy480-05.078 104,995
sy480-05.079 99,690
sy480-05.080 105,082
ssj_ops@100% 8,360,150
ssj_ops@100% per JVM 104,502
Graph of per-instance results
JVM 'sy480-05.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,099
Calibration 2     106,617
Calibration 3     106,467
ssj_ops@calibrated=106,542
100% 100.4% 106,542 106,996
90% 90.4% 95,888 96,305
80% 80.3% 85,234 85,540
70% 70.6% 74,579 75,268
60% 59.7% 63,925 63,557
50% 49.7% 53,271 52,931
40% 40.7% 42,617 43,354
30% 30.4% 31,963 32,438
20% 19.8% 21,308 21,088
10% 9.8% 10,654 10,400
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     78,310
Calibration 2     96,863
Calibration 3     96,331
ssj_ops@calibrated=96,597
100% 99.4% 96,597 95,972
90% 90.0% 86,937 86,972
80% 80.4% 77,277 77,681
70% 69.0% 67,618 66,607
60% 59.8% 57,958 57,777
50% 50.7% 48,298 49,022
40% 40.0% 38,639 38,625
30% 29.7% 28,979 28,649
20% 19.9% 19,319 19,185
10% 10.2% 9,660 9,859
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,190
Calibration 2     101,888
Calibration 3     101,808
ssj_ops@calibrated=101,848
100% 99.9% 101,848 101,753
90% 89.7% 91,663 91,318
80% 80.5% 81,479 81,949
70% 69.6% 71,294 70,864
60% 60.5% 61,109 61,617
50% 50.2% 50,924 51,150
40% 40.5% 40,739 41,236
30% 29.3% 30,554 29,868
20% 20.1% 20,370 20,444
10% 10.0% 10,185 10,212
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,866
Calibration 2     105,764
Calibration 3     105,699
ssj_ops@calibrated=105,732
100% 99.9% 105,732 105,624
90% 89.2% 95,158 94,260
80% 80.0% 84,585 84,579
70% 70.0% 74,012 74,022
60% 59.3% 63,439 62,741
50% 49.4% 52,866 52,203
40% 40.0% 42,293 42,268
30% 30.1% 31,719 31,797
20% 20.2% 21,146 21,350
10% 10.0% 10,573 10,564
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,607
Calibration 2     105,411
Calibration 3     105,265
ssj_ops@calibrated=105,338
100% 99.4% 105,338 104,738
90% 89.7% 94,804 94,482
80% 80.4% 84,270 84,662
70% 69.7% 73,737 73,446
60% 59.8% 63,203 62,977
50% 49.6% 52,669 52,258
40% 39.6% 42,135 41,747
30% 30.1% 31,601 31,717
20% 20.3% 21,068 21,376
10% 10.3% 10,534 10,875
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,663
Calibration 2     107,448
Calibration 3     107,339
ssj_ops@calibrated=107,393
100% 100.3% 107,393 107,696
90% 90.2% 96,654 96,823
80% 80.7% 85,915 86,719
70% 69.8% 75,175 74,936
60% 60.4% 64,436 64,820
50% 49.7% 53,697 53,411
40% 39.2% 42,957 42,131
30% 30.0% 32,218 32,183
20% 20.3% 21,479 21,841
10% 10.3% 10,739 11,028
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.007' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,175
Calibration 2     106,601
Calibration 3     106,599
ssj_ops@calibrated=106,600
100% 99.9% 106,600 106,456
90% 89.9% 95,940 95,882
80% 80.0% 85,280 85,274
70% 70.1% 74,620 74,708
60% 59.5% 63,960 63,446
50% 49.8% 53,300 53,089
40% 39.9% 42,640 42,507
30% 30.1% 31,980 32,073
20% 19.9% 21,320 21,226
10% 9.9% 10,660 10,550
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.008' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,720
Calibration 2     106,838
Calibration 3     106,834
ssj_ops@calibrated=106,836
100% 100.1% 106,836 106,990
90% 89.9% 96,153 96,041
80% 80.2% 85,469 85,690
70% 70.0% 74,786 74,736
60% 60.0% 64,102 64,055
50% 49.3% 53,418 52,687
40% 39.8% 42,735 42,513
30% 30.4% 32,051 32,459
20% 20.3% 21,367 21,680
10% 10.0% 10,684 10,675
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.009' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,980
Calibration 2     108,021
Calibration 3     108,006
ssj_ops@calibrated=108,014
100% 99.7% 108,014 107,699
90% 90.1% 97,212 97,315
80% 79.6% 86,411 85,958
70% 69.5% 75,609 75,091
60% 60.0% 64,808 64,815
50% 49.5% 54,007 53,423
40% 39.6% 43,205 42,814
30% 29.8% 32,404 32,207
20% 20.0% 21,603 21,637
10% 9.7% 10,801 10,500
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.010' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,276
Calibration 2     103,515
Calibration 3     103,584
ssj_ops@calibrated=103,549
100% 99.8% 103,549 103,354
90% 90.3% 93,194 93,546
80% 80.4% 82,839 83,267
70% 70.0% 72,485 72,445
60% 59.6% 62,130 61,753
50% 49.7% 51,775 51,472
40% 40.1% 41,420 41,529
30% 29.4% 31,065 30,446
20% 20.1% 20,710 20,821
10% 10.1% 10,355 10,508
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.011' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,461
Calibration 2     103,936
Calibration 3     104,249
ssj_ops@calibrated=104,092
100% 99.3% 104,092 103,402
90% 90.7% 93,683 94,402
80% 79.8% 83,274 83,042
70% 69.9% 72,865 72,712
60% 59.9% 62,455 62,312
50% 49.6% 52,046 51,609
40% 39.6% 41,637 41,263
30% 30.7% 31,228 31,954
20% 19.7% 20,818 20,515
10% 10.1% 10,409 10,537
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.012' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,511
Calibration 2     106,692
Calibration 3     106,466
ssj_ops@calibrated=106,579
100% 99.2% 106,579 105,714
90% 89.6% 95,921 95,500
80% 79.8% 85,264 85,092
70% 69.4% 74,606 73,939
60% 58.8% 63,948 62,633
50% 50.0% 53,290 53,278
40% 39.6% 42,632 42,233
30% 29.9% 31,974 31,841
20% 20.2% 21,316 21,520
10% 10.0% 10,658 10,621
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.013' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,613
Calibration 2     100,978
Calibration 3     101,020
ssj_ops@calibrated=100,999
100% 98.3% 100,999 99,258
90% 89.4% 90,899 90,304
80% 79.2% 80,799 80,035
70% 69.9% 70,699 70,604
60% 59.4% 60,599 60,032
50% 50.0% 50,499 50,455
40% 40.2% 40,400 40,573
30% 30.4% 30,300 30,698
20% 20.3% 20,200 20,505
10% 10.1% 10,100 10,175
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.014' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,207
Calibration 2     104,338
Calibration 3     104,352
ssj_ops@calibrated=104,345
100% 99.9% 104,345 104,189
90% 90.0% 93,910 93,884
80% 81.2% 83,476 84,677
70% 70.6% 73,041 73,665
60% 60.3% 62,607 62,941
50% 49.5% 52,172 51,619
40% 40.8% 41,738 42,586
30% 30.4% 31,303 31,760
20% 20.2% 20,869 21,039
10% 10.0% 10,434 10,471
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.015' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,437
Calibration 2     105,066
Calibration 3     105,151
ssj_ops@calibrated=105,108
100% 99.8% 105,108 104,913
90% 88.6% 94,598 93,090
80% 79.6% 84,087 83,626
70% 69.6% 73,576 73,125
60% 60.0% 63,065 63,021
50% 50.1% 52,554 52,613
40% 40.1% 42,043 42,188
30% 29.9% 31,533 31,451
20% 20.5% 21,022 21,509
10% 10.2% 10,511 10,687
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.016' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,142
Calibration 2     102,517
Calibration 3     102,600
ssj_ops@calibrated=102,558
100% 100.2% 102,558 102,803
90% 90.4% 92,302 92,751
80% 80.3% 82,047 82,326
70% 70.0% 71,791 71,822
60% 60.0% 61,535 61,515
50% 50.2% 51,279 51,436
40% 40.4% 41,023 41,467
30% 30.0% 30,767 30,814
20% 20.3% 20,512 20,793
10% 9.8% 10,256 10,070
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.017' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,642
Calibration 2     103,800
Calibration 3     103,891
ssj_ops@calibrated=103,845
100% 100.0% 103,845 103,845
90% 90.4% 93,461 93,839
80% 80.9% 83,076 84,020
70% 69.8% 72,692 72,532
60% 59.5% 62,307 61,775
50% 50.4% 51,923 52,388
40% 39.9% 41,538 41,392
30% 30.5% 31,154 31,636
20% 19.6% 20,769 20,382
10% 10.3% 10,385 10,650
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.018' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,700
Calibration 2     106,210
Calibration 3     106,002
ssj_ops@calibrated=106,106
100% 99.6% 106,106 105,647
90% 89.7% 95,495 95,211
80% 79.5% 84,885 84,396
70% 71.0% 74,274 75,368
60% 60.4% 63,664 64,137
50% 50.3% 53,053 53,420
40% 40.0% 42,442 42,460
30% 30.1% 31,832 31,913
20% 19.8% 21,221 21,033
10% 9.8% 10,611 10,450
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.019' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,155
Calibration 2     100,628
Calibration 3     100,717
ssj_ops@calibrated=100,672
100% 99.6% 100,672 100,274
90% 90.6% 90,605 91,195
80% 79.9% 80,538 80,435
70% 71.8% 70,471 72,305
60% 59.7% 60,403 60,134
50% 49.4% 50,336 49,708
40% 39.5% 40,269 39,772
30% 30.1% 30,202 30,353
20% 19.6% 20,134 19,756
10% 10.1% 10,067 10,175
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.020' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,507
Calibration 2     99,625
Calibration 3     99,690
ssj_ops@calibrated=99,657
100% 99.2% 99,657 98,843
90% 89.3% 89,692 88,976
80% 80.7% 79,726 80,399
70% 70.7% 69,760 70,504
60% 60.2% 59,794 59,945
50% 49.8% 49,829 49,587
40% 40.4% 39,863 40,263
30% 30.1% 29,897 29,958
20% 20.0% 19,931 19,912
10% 10.2% 9,966 10,122
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.021' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,680
Calibration 2     106,660
Calibration 3     106,772
ssj_ops@calibrated=106,716
100% 99.9% 106,716 106,581
90% 89.8% 96,045 95,816
80% 79.5% 85,373 84,856
70% 68.9% 74,701 73,566
60% 59.3% 64,030 63,316
50% 50.0% 53,358 53,341
40% 39.1% 42,686 41,778
30% 30.7% 32,015 32,791
20% 19.6% 21,343 20,950
10% 9.8% 10,672 10,452
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.022' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,269
Calibration 2     107,142
Calibration 3     107,185
ssj_ops@calibrated=107,163
100% 99.6% 107,163 106,770
90% 90.3% 96,447 96,807
80% 80.5% 85,731 86,263
70% 70.1% 75,014 75,076
60% 60.0% 64,298 64,346
50% 50.9% 53,582 54,584
40% 39.6% 42,865 42,466
30% 30.7% 32,149 32,922
20% 20.0% 21,433 21,425
10% 9.7% 10,716 10,348
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.023' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,528
Calibration 2     103,753
Calibration 3     103,998
ssj_ops@calibrated=103,876
100% 100.3% 103,876 104,137
90% 89.6% 93,488 93,046
80% 80.5% 83,101 83,593
70% 68.9% 72,713 71,561
60% 59.5% 62,325 61,781
50% 50.4% 51,938 52,312
40% 40.4% 41,550 41,919
30% 29.8% 31,163 30,963
20% 20.0% 20,775 20,777
10% 9.9% 10,388 10,325
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.024' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,507
Calibration 2     101,305
Calibration 3     101,340
ssj_ops@calibrated=101,323
100% 99.7% 101,323 101,029
90% 89.5% 91,190 90,692
80% 80.0% 81,058 81,019
70% 70.1% 70,926 71,061
60% 60.5% 60,794 61,280
50% 50.3% 50,661 51,014
40% 39.0% 40,529 39,538
30% 30.3% 30,397 30,736
20% 19.9% 20,265 20,200
10% 10.0% 10,132 10,121
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.025' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,229
Calibration 2     103,237
Calibration 3     103,315
ssj_ops@calibrated=103,276
100% 100.0% 103,276 103,311
90% 90.7% 92,948 93,710
80% 79.6% 82,621 82,172
70% 70.3% 72,293 72,597
60% 60.9% 61,966 62,861
50% 49.4% 51,638 51,035
40% 39.8% 41,310 41,091
30% 29.4% 30,983 30,347
20% 20.4% 20,655 21,062
10% 9.9% 10,328 10,275
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.026' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,460
Calibration 2     107,000
Calibration 3     107,136
ssj_ops@calibrated=107,068
100% 99.8% 107,068 106,852
90% 89.6% 96,362 95,887
80% 80.0% 85,655 85,690
70% 71.0% 74,948 76,049
60% 59.8% 64,241 63,989
50% 50.6% 53,534 54,230
40% 39.7% 42,827 42,547
30% 29.8% 32,121 31,864
20% 20.2% 21,414 21,655
10% 10.0% 10,707 10,660
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.027' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,152
Calibration 2     101,568
Calibration 3     101,626
ssj_ops@calibrated=101,597
100% 99.9% 101,597 101,484
90% 89.4% 91,438 90,799
80% 79.6% 81,278 80,828
70% 70.2% 71,118 71,344
60% 60.1% 60,958 61,089
50% 50.3% 50,799 51,076
40% 40.2% 40,639 40,889
30% 29.6% 30,479 30,071
20% 20.0% 20,319 20,298
10% 10.0% 10,160 10,208
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.028' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,162
Calibration 2     106,219
Calibration 3     106,300
ssj_ops@calibrated=106,259
100% 99.6% 106,259 105,801
90% 89.6% 95,633 95,188
80% 80.2% 85,008 85,242
70% 70.9% 74,382 75,353
60% 58.8% 63,756 62,489
50% 49.4% 53,130 52,490
40% 40.4% 42,504 42,876
30% 30.2% 31,878 32,095
20% 20.1% 21,252 21,379
10% 9.6% 10,626 10,225
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.029' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,479
Calibration 2     106,859
Calibration 3     106,988
ssj_ops@calibrated=106,923
100% 100.1% 106,923 107,073
90% 90.8% 96,231 97,085
80% 79.6% 85,539 85,161
70% 70.3% 74,846 75,169
60% 59.7% 64,154 63,839
50% 50.2% 53,462 53,639
40% 40.3% 42,769 43,064
30% 30.1% 32,077 32,230
20% 19.9% 21,385 21,325
10% 9.9% 10,692 10,548
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.030' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,484
Calibration 2     106,085
Calibration 3     106,276
ssj_ops@calibrated=106,181
100% 100.3% 106,181 106,521
90% 89.3% 95,563 94,807
80% 80.1% 84,945 85,092
70% 70.8% 74,326 75,213
60% 59.9% 63,708 63,618
50% 50.2% 53,090 53,262
40% 39.9% 42,472 42,409
30% 30.0% 31,854 31,897
20% 19.8% 21,236 21,076
10% 9.9% 10,618 10,487
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.031' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,581
Calibration 2     103,557
Calibration 3     103,664
ssj_ops@calibrated=103,610
100% 99.6% 103,610 103,157
90% 90.2% 93,249 93,411
80% 79.7% 82,888 82,623
70% 69.8% 72,527 72,281
60% 59.8% 62,166 61,915
50% 48.9% 51,805 50,696
40% 40.6% 41,444 42,029
30% 30.4% 31,083 31,478
20% 19.9% 20,722 20,607
10% 9.8% 10,361 10,196
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.032' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,261
Calibration 2     105,743
Calibration 3     105,905
ssj_ops@calibrated=105,824
100% 99.9% 105,824 105,736
90% 89.5% 95,241 94,758
80% 79.9% 84,659 84,561
70% 69.9% 74,077 73,934
60% 59.6% 63,494 63,116
50% 49.6% 52,912 52,496
40% 40.2% 42,329 42,575
30% 30.2% 31,747 31,929
20% 19.7% 21,165 20,858
10% 10.2% 10,582 10,794
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.033' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,284
Calibration 2     107,089
Calibration 3     107,248
ssj_ops@calibrated=107,169
100% 99.4% 107,169 106,546
90% 89.9% 96,452 96,308
80% 80.0% 85,735 85,784
70% 69.8% 75,018 74,827
60% 59.9% 64,301 64,145
50% 50.2% 53,584 53,788
40% 39.8% 42,867 42,660
30% 30.0% 32,151 32,167
20% 20.0% 21,434 21,446
10% 10.0% 10,717 10,750
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.034' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,608
Calibration 2     105,537
Calibration 3     105,706
ssj_ops@calibrated=105,621
100% 99.5% 105,621 105,093
90% 90.4% 95,059 95,429
80% 80.3% 84,497 84,817
70% 70.8% 73,935 74,811
60% 60.2% 63,373 63,589
50% 50.1% 52,811 52,919
40% 39.6% 42,249 41,854
30% 29.7% 31,686 31,402
20% 20.3% 21,124 21,390
10% 10.1% 10,562 10,629
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.035' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,185
Calibration 2     104,809
Calibration 3     104,763
ssj_ops@calibrated=104,786
100% 99.8% 104,786 104,588
90% 90.6% 94,307 94,962
80% 79.9% 83,829 83,688
70% 70.5% 73,350 73,834
60% 59.2% 62,871 62,067
50% 50.9% 52,393 53,379
40% 40.1% 41,914 42,002
30% 30.4% 31,436 31,845
20% 20.1% 20,957 21,039
10% 10.2% 10,479 10,664
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.036' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,575
Calibration 2     104,594
Calibration 3     104,265
ssj_ops@calibrated=104,430
100% 98.5% 104,430 102,830
90% 90.8% 93,987 94,777
80% 79.6% 83,544 83,128
70% 70.0% 73,101 73,114
60% 60.4% 62,658 63,062
50% 50.5% 52,215 52,688
40% 40.4% 41,772 42,220
30% 30.3% 31,329 31,643
20% 19.2% 20,886 20,085
10% 9.2% 10,443 9,653
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.037' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,921
Calibration 2     105,912
Calibration 3     105,546
ssj_ops@calibrated=105,729
100% 99.7% 105,729 105,369
90% 89.8% 95,156 94,927
80% 79.4% 84,583 83,978
70% 69.9% 74,010 73,879
60% 59.6% 63,437 62,980
50% 49.8% 52,865 52,677
40% 39.4% 42,292 41,618
30% 29.9% 31,719 31,602
20% 19.8% 21,146 20,975
10% 10.0% 10,573 10,575
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.038' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,788
Calibration 2     105,266
Calibration 3     105,286
ssj_ops@calibrated=105,276
100% 99.5% 105,276 104,747
90% 89.4% 94,748 94,071
80% 80.1% 84,221 84,374
70% 69.7% 73,693 73,380
60% 59.8% 63,166 63,007
50% 50.6% 52,638 53,305
40% 39.7% 42,110 41,802
30% 30.2% 31,583 31,742
20% 20.1% 21,055 21,166
10% 10.1% 10,528 10,621
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.039' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,396
Calibration 2     106,917
Calibration 3     106,998
ssj_ops@calibrated=106,958
100% 99.4% 106,958 106,346
90% 89.8% 96,262 96,082
80% 80.0% 85,566 85,523
70% 69.8% 74,870 74,653
60% 59.9% 64,175 64,090
50% 50.2% 53,479 53,686
40% 40.3% 42,783 43,070
30% 30.2% 32,087 32,281
20% 20.1% 21,392 21,497
10% 9.8% 10,696 10,493
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.040' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,899
Calibration 2     105,271
Calibration 3     105,455
ssj_ops@calibrated=105,363
100% 99.5% 105,363 104,829
90% 89.5% 94,827 94,335
80% 80.3% 84,291 84,588
70% 70.3% 73,754 74,070
60% 59.7% 63,218 62,871
50% 50.1% 52,682 52,816
40% 39.4% 42,145 41,488
30% 30.2% 31,609 31,827
20% 20.4% 21,073 21,458
10% 9.6% 10,536 10,167
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.041' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,859
Calibration 2     105,824
Calibration 3     105,626
ssj_ops@calibrated=105,725
100% 99.8% 105,725 105,482
90% 89.7% 95,152 94,837
80% 79.7% 84,580 84,315
70% 70.0% 74,007 74,045
60% 60.2% 63,435 63,649
50% 50.6% 52,862 53,455
40% 40.3% 42,290 42,628
30% 29.5% 31,717 31,150
20% 20.4% 21,145 21,536
10% 10.0% 10,572 10,597
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.042' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,268
Calibration 2     105,379
Calibration 3     105,570
ssj_ops@calibrated=105,474
100% 99.5% 105,474 104,993
90% 90.4% 94,927 95,361
80% 79.9% 84,380 84,301
70% 69.8% 73,832 73,653
60% 60.1% 63,285 63,351
50% 51.1% 52,737 53,943
40% 40.2% 42,190 42,360
30% 29.8% 31,642 31,467
20% 19.8% 21,095 20,837
10% 9.8% 10,547 10,333
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.043' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,074
Calibration 2     97,310
Calibration 3     97,434
ssj_ops@calibrated=97,372
100% 100.0% 97,372 97,418
90% 90.1% 87,635 87,761
80% 80.6% 77,898 78,463
70% 70.6% 68,161 68,769
60% 59.0% 58,423 57,486
50% 50.7% 48,686 49,403
40% 40.6% 38,949 39,495
30% 29.6% 29,212 28,810
20% 19.3% 19,474 18,798
10% 10.0% 9,737 9,733
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.044' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,778
Calibration 2     105,927
Calibration 3     106,085
ssj_ops@calibrated=106,006
100% 100.1% 106,006 106,111
90% 90.8% 95,405 96,255
80% 80.5% 84,805 85,364
70% 70.1% 74,204 74,286
60% 60.5% 63,604 64,149
50% 49.7% 53,003 52,727
40% 39.9% 42,402 42,311
30% 29.4% 31,802 31,134
20% 19.6% 21,201 20,762
10% 9.7% 10,601 10,329
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.045' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,975
Calibration 2     105,373
Calibration 3     106,447
ssj_ops@calibrated=105,910
100% 100.1% 105,910 105,981
90% 88.8% 95,319 94,018
80% 79.9% 84,728 84,673
70% 69.6% 74,137 73,753
60% 60.5% 63,546 64,045
50% 50.2% 52,955 53,182
40% 40.4% 42,364 42,809
30% 30.6% 31,773 32,363
20% 19.8% 21,182 21,014
10% 9.9% 10,591 10,509
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.046' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,089
Calibration 2     107,258
Calibration 3     107,204
ssj_ops@calibrated=107,231
100% 99.6% 107,231 106,804
90% 88.9% 96,508 95,309
80% 80.3% 85,785 86,123
70% 70.1% 75,062 75,205
60% 60.7% 64,338 65,117
50% 49.6% 53,615 53,236
40% 40.7% 42,892 43,683
30% 30.0% 32,169 32,140
20% 19.8% 21,446 21,277
10% 9.8% 10,723 10,458
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.047' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,387
Calibration 2     106,119
Calibration 3     106,145
ssj_ops@calibrated=106,132
100% 99.1% 106,132 105,147
90% 91.0% 95,519 96,553
80% 79.8% 84,906 84,706
70% 69.9% 74,292 74,228
60% 59.8% 63,679 63,485
50% 49.5% 53,066 52,555
40% 39.8% 42,453 42,285
30% 30.4% 31,840 32,222
20% 19.5% 21,226 20,720
10% 10.0% 10,613 10,624
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.048' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,374
Calibration 2     107,563
Calibration 3     107,510
ssj_ops@calibrated=107,536
100% 99.3% 107,536 106,796
90% 89.9% 96,783 96,677
80% 78.6% 86,029 84,516
70% 69.0% 75,275 74,250
60% 60.7% 64,522 65,279
50% 49.6% 53,768 53,345
40% 40.1% 43,015 43,103
30% 30.6% 32,261 32,931
20% 20.1% 21,507 21,561
10% 9.5% 10,754 10,267
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.049' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,310
Calibration 2     107,028
Calibration 3     106,925
ssj_ops@calibrated=106,977
100% 99.8% 106,977 106,802
90% 89.0% 96,279 95,258
80% 79.5% 85,581 85,063
70% 70.4% 74,884 75,272
60% 61.0% 64,186 65,220
50% 50.0% 53,488 53,497
40% 40.2% 42,791 42,992
30% 30.1% 32,093 32,163
20% 19.7% 21,395 21,055
10% 9.8% 10,698 10,469
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.050' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,604
Calibration 2     105,324
Calibration 3     105,309
ssj_ops@calibrated=105,317
100% 99.7% 105,317 105,004
90% 90.4% 94,785 95,202
80% 80.0% 84,253 84,302
70% 69.8% 73,722 73,560
60% 60.6% 63,190 63,776
50% 50.3% 52,658 52,944
40% 40.1% 42,127 42,279
30% 30.0% 31,595 31,574
20% 20.2% 21,063 21,312
10% 10.2% 10,532 10,789
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.051' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,847
Calibration 2     105,844
Calibration 3     105,740
ssj_ops@calibrated=105,792
100% 99.9% 105,792 105,718
90% 89.6% 95,213 94,737
80% 79.7% 84,633 84,315
70% 70.0% 74,054 74,047
60% 60.2% 63,475 63,684
50% 49.8% 52,896 52,725
40% 40.5% 42,317 42,811
30% 30.2% 31,738 31,964
20% 19.8% 21,158 20,941
10% 9.9% 10,579 10,504
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.052' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,686
Calibration 2     104,664
Calibration 3     104,730
ssj_ops@calibrated=104,697
100% 99.5% 104,697 104,207
90% 89.8% 94,227 94,021
80% 80.2% 83,758 83,993
70% 70.2% 73,288 73,535
60% 60.0% 62,818 62,820
50% 49.8% 52,349 52,148
40% 39.4% 41,879 41,241
30% 29.8% 31,409 31,218
20% 19.7% 20,939 20,626
10% 9.9% 10,470 10,410
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.053' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,783
Calibration 2     105,323
Calibration 3     105,341
ssj_ops@calibrated=105,332
100% 99.9% 105,332 105,222
90% 90.4% 94,799 95,242
80% 78.9% 84,266 83,134
70% 69.2% 73,732 72,916
60% 59.2% 63,199 62,369
50% 49.5% 52,666 52,156
40% 40.8% 42,133 42,943
30% 30.0% 31,600 31,594
20% 19.9% 21,066 20,975
10% 9.8% 10,533 10,279
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.054' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,025
Calibration 2     105,618
Calibration 3     105,439
ssj_ops@calibrated=105,528
100% 99.3% 105,528 104,766
90% 89.3% 94,976 94,199
80% 81.2% 84,423 85,639
70% 70.0% 73,870 73,851
60% 59.3% 63,317 62,593
50% 49.7% 52,764 52,450
40% 39.7% 42,211 41,872
30% 30.7% 31,659 32,431
20% 20.5% 21,106 21,621
10% 10.2% 10,553 10,750
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.055' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,821
Calibration 2     103,598
Calibration 3     104,070
ssj_ops@calibrated=103,834
100% 99.6% 103,834 103,438
90% 90.2% 93,451 93,638
80% 80.2% 83,067 83,253
70% 69.7% 72,684 72,367
60% 59.9% 62,300 62,186
50% 50.1% 51,917 52,057
40% 40.5% 41,534 42,003
30% 29.8% 31,150 30,979
20% 19.5% 20,767 20,247
10% 9.8% 10,383 10,200
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.056' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,571
Calibration 2     106,551
Calibration 3     106,425
ssj_ops@calibrated=106,488
100% 99.6% 106,488 106,049
90% 89.5% 95,839 95,280
80% 80.6% 85,190 85,793
70% 70.0% 74,541 74,526
60% 59.8% 63,893 63,633
50% 49.7% 53,244 52,926
40% 40.4% 42,595 43,012
30% 30.0% 31,946 31,915
20% 19.9% 21,298 21,143
10% 9.8% 10,649 10,454
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.057' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,454
Calibration 2     104,151
Calibration 3     104,322
ssj_ops@calibrated=104,236
100% 100.0% 104,236 104,255
90% 91.2% 93,813 95,111
80% 80.4% 83,389 83,755
70% 69.6% 72,966 72,562
60% 60.5% 62,542 63,041
50% 49.7% 52,118 51,774
40% 39.7% 41,695 41,422
30% 30.2% 31,271 31,455
20% 19.9% 20,847 20,760
10% 10.1% 10,424 10,535
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.058' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,652
Calibration 2     106,437
Calibration 3     106,619
ssj_ops@calibrated=106,528
100% 100.1% 106,528 106,664
90% 89.0% 95,875 94,803
80% 80.1% 85,222 85,347
70% 70.6% 74,570 75,198
60% 59.4% 63,917 63,301
50% 50.3% 53,264 53,626
40% 39.7% 42,611 42,290
30% 29.5% 31,958 31,445
20% 20.5% 21,306 21,871
10% 10.0% 10,653 10,633
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.059' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,587
Calibration 2     104,449
Calibration 3     104,480
ssj_ops@calibrated=104,464
100% 98.8% 104,464 103,189
90% 90.3% 94,018 94,307
80% 80.3% 83,572 83,895
70% 70.0% 73,125 73,153
60% 60.0% 62,679 62,712
50% 50.6% 52,232 52,809
40% 39.5% 41,786 41,286
30% 30.0% 31,339 31,369
20% 19.9% 20,893 20,820
10% 10.0% 10,446 10,460
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.060' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,744
Calibration 2     103,937
Calibration 3     103,794
ssj_ops@calibrated=103,866
100% 99.6% 103,866 103,476
90% 89.0% 93,479 92,441
80% 79.4% 83,093 82,490
70% 70.2% 72,706 72,889
60% 60.0% 62,319 62,348
50% 49.4% 51,933 51,285
40% 39.8% 41,546 41,339
30% 29.6% 31,160 30,794
20% 19.9% 20,773 20,648
10% 9.8% 10,387 10,179
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.061' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,784
Calibration 2     105,647
Calibration 3     105,934
ssj_ops@calibrated=105,790
100% 99.4% 105,790 105,187
90% 90.3% 95,211 95,488
80% 79.5% 84,632 84,109
70% 70.2% 74,053 74,295
60% 59.2% 63,474 62,641
50% 50.7% 52,895 53,595
40% 40.3% 42,316 42,625
30% 30.2% 31,737 31,965
20% 20.4% 21,158 21,562
10% 10.0% 10,579 10,596
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.062' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,648
Calibration 2     98,800
Calibration 3     98,958
ssj_ops@calibrated=98,879
100% 99.0% 98,879 97,905
90% 89.1% 88,991 88,107
80% 80.0% 79,103 79,141
70% 69.6% 69,215 68,822
60% 59.8% 59,327 59,169
50% 50.7% 49,440 50,104
40% 39.9% 39,552 39,443
30% 29.9% 29,664 29,607
20% 19.8% 19,776 19,612
10% 9.8% 9,888 9,705
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.063' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,973
Calibration 2     104,986
Calibration 3     105,165
ssj_ops@calibrated=105,075
100% 98.9% 105,075 103,910
90% 89.7% 94,568 94,263
80% 79.8% 84,060 83,886
70% 71.0% 73,553 74,570
60% 59.5% 63,045 62,484
50% 50.3% 52,538 52,882
40% 40.1% 42,030 42,124
30% 30.4% 31,523 31,924
20% 19.7% 21,015 20,743
10% 10.1% 10,508 10,609
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.064' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,550
Calibration 2     105,370
Calibration 3     105,390
ssj_ops@calibrated=105,380
100% 99.3% 105,380 104,592
90% 90.6% 94,842 95,460
80% 79.9% 84,304 84,152
70% 69.8% 73,766 73,565
60% 59.9% 63,228 63,087
50% 49.3% 52,690 51,925
40% 39.1% 42,152 41,249
30% 29.7% 31,614 31,349
20% 20.3% 21,076 21,350
10% 10.4% 10,538 10,925
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.065' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,819
Calibration 2     103,835
Calibration 3     103,603
ssj_ops@calibrated=103,719
100% 100.2% 103,719 103,915
90% 89.4% 93,347 92,771
80% 79.5% 82,975 82,444
70% 70.4% 72,603 72,993
60% 60.2% 62,232 62,391
50% 50.6% 51,860 52,467
40% 39.6% 41,488 41,076
30% 29.4% 31,116 30,473
20% 20.1% 20,744 20,823
10% 10.0% 10,372 10,329
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.066' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,756
Calibration 2     106,340
Calibration 3     106,455
ssj_ops@calibrated=106,398
100% 99.1% 106,398 105,452
90% 89.8% 95,758 95,590
80% 79.4% 85,118 84,465
70% 70.0% 74,479 74,458
60% 60.2% 63,839 64,017
50% 49.4% 53,199 52,555
40% 41.0% 42,559 43,576
30% 30.3% 31,919 32,250
20% 19.9% 21,280 21,176
10% 10.1% 10,640 10,695
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.067' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,681
Calibration 2     104,621
Calibration 3     104,767
ssj_ops@calibrated=104,694
100% 98.9% 104,694 103,546
90% 89.6% 94,225 93,843
80% 78.5% 83,755 82,195
70% 70.5% 73,286 73,781
60% 59.7% 62,817 62,542
50% 49.4% 52,347 51,710
40% 39.4% 41,878 41,279
30% 30.0% 31,408 31,372
20% 19.8% 20,939 20,779
10% 9.9% 10,469 10,404
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.068' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,276
Calibration 2     105,332
Calibration 3     105,542
ssj_ops@calibrated=105,437
100% 100.2% 105,437 105,605
90% 91.0% 94,893 95,905
80% 79.8% 84,350 84,123
70% 70.6% 73,806 74,448
60% 60.7% 63,262 64,020
50% 49.4% 52,719 52,135
40% 39.9% 42,175 42,046
30% 30.2% 31,631 31,875
20% 20.4% 21,087 21,503
10% 9.9% 10,544 10,472
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.069' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,561
Calibration 2     105,010
Calibration 3     104,919
ssj_ops@calibrated=104,965
100% 99.9% 104,965 104,815
90% 89.4% 94,468 93,805
80% 80.2% 83,972 84,165
70% 70.0% 73,475 73,520
60% 59.4% 62,979 62,388
50% 50.4% 52,482 52,879
40% 40.7% 41,986 42,707
30% 29.4% 31,489 30,844
20% 20.1% 20,993 21,090
10% 9.8% 10,496 10,268
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.070' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,833
Calibration 2     102,805
Calibration 3     102,927
ssj_ops@calibrated=102,866
100% 99.5% 102,866 102,401
90% 89.6% 92,579 92,151
80% 80.3% 82,293 82,653
70% 71.4% 72,006 73,472
60% 60.6% 61,720 62,327
50% 49.7% 51,433 51,175
40% 40.1% 41,146 41,288
30% 30.0% 30,860 30,879
20% 19.6% 20,573 20,166
10% 10.1% 10,287 10,412
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.071' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,587
Calibration 2     108,978
Calibration 3     109,238
ssj_ops@calibrated=109,108
100% 100.0% 109,108 109,095
90% 90.1% 98,198 98,261
80% 80.3% 87,287 87,626
70% 70.4% 76,376 76,816
60% 59.0% 65,465 64,330
50% 50.2% 54,554 54,817
40% 40.2% 43,643 43,819
30% 30.4% 32,733 33,157
20% 19.7% 21,822 21,466
10% 9.7% 10,911 10,599
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.072' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,702
Calibration 2     106,590
Calibration 3     106,631
ssj_ops@calibrated=106,610
100% 99.9% 106,610 106,454
90% 89.7% 95,949 95,603
80% 80.6% 85,288 85,944
70% 70.0% 74,627 74,619
60% 59.7% 63,966 63,613
50% 49.9% 53,305 53,237
40% 40.3% 42,644 42,981
30% 29.8% 31,983 31,756
20% 20.5% 21,322 21,843
10% 10.3% 10,661 10,979
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.073' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,219
Calibration 2     106,567
Calibration 3     106,662
ssj_ops@calibrated=106,614
100% 100.2% 106,614 106,802
90% 89.3% 95,953 95,216
80% 79.3% 85,291 84,556
70% 70.1% 74,630 74,765
60% 60.5% 63,969 64,510
50% 50.6% 53,307 53,968
40% 39.7% 42,646 42,336
30% 30.4% 31,984 32,459
20% 20.1% 21,323 21,454
10% 9.9% 10,661 10,533
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.074' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,538
Calibration 2     106,260
Calibration 3     106,503
ssj_ops@calibrated=106,381
100% 99.8% 106,381 106,166
90% 89.0% 95,743 94,628
80% 80.3% 85,105 85,461
70% 70.0% 74,467 74,448
60% 60.7% 63,829 64,549
50% 49.2% 53,191 52,288
40% 40.0% 42,553 42,581
30% 30.4% 31,914 32,374
20% 19.9% 21,276 21,129
10% 10.2% 10,638 10,851
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.075' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,564
Calibration 2     100,865
Calibration 3     101,072
ssj_ops@calibrated=100,968
100% 99.4% 100,968 100,382
90% 89.8% 90,872 90,653
80% 80.4% 80,775 81,194
70% 70.1% 70,678 70,793
60% 59.8% 60,581 60,406
50% 49.7% 50,484 50,132
40% 40.7% 40,387 41,099
30% 29.9% 30,291 30,224
20% 19.7% 20,194 19,854
10% 10.3% 10,097 10,377
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.076' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,930
Calibration 2     106,404
Calibration 3     106,588
ssj_ops@calibrated=106,496
100% 99.4% 106,496 105,884
90% 90.2% 95,847 96,069
80% 80.4% 85,197 85,646
70% 69.9% 74,547 74,441
60% 60.2% 63,898 64,097
50% 50.3% 53,248 53,597
40% 40.2% 42,599 42,788
30% 30.2% 31,949 32,129
20% 20.0% 21,299 21,351
10% 10.3% 10,650 11,020
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.077' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,496
Calibration 2     107,082
Calibration 3     107,118
ssj_ops@calibrated=107,100
100% 98.8% 107,100 105,786
90% 90.3% 96,390 96,678
80% 79.8% 85,680 85,436
70% 70.1% 74,970 75,111
60% 60.0% 64,260 64,241
50% 50.0% 53,550 53,546
40% 40.3% 42,840 43,120
30% 29.7% 32,130 31,792
20% 19.8% 21,420 21,251
10% 10.0% 10,710 10,663
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.078' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,131
Calibration 2     105,282
Calibration 3     105,262
ssj_ops@calibrated=105,272
100% 99.7% 105,272 104,995
90% 89.8% 94,745 94,487
80% 79.7% 84,218 83,855
70% 69.7% 73,691 73,392
60% 60.4% 63,163 63,579
50% 49.6% 52,636 52,209
40% 39.7% 42,109 41,832
30% 30.1% 31,582 31,728
20% 19.6% 21,054 20,583
10% 10.0% 10,527 10,577
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.079' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,665
Calibration 2     99,883
Calibration 3     100,253
ssj_ops@calibrated=100,068
100% 99.6% 100,068 99,690
90% 90.6% 90,061 90,624
80% 79.1% 80,054 79,145
70% 69.8% 70,048 69,851
60% 60.1% 60,041 60,092
50% 49.7% 50,034 49,760
40% 39.7% 40,027 39,749
30% 30.6% 30,020 30,639
20% 20.0% 20,014 20,045
10% 9.8% 10,007 9,854
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'sy480-05.080' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,353
Calibration 2     105,449
Calibration 3     105,249
ssj_ops@calibrated=105,349
100% 99.7% 105,349 105,082
90% 90.1% 94,814 94,911
80% 79.8% 84,279 84,110
70% 69.4% 73,744 73,134
60% 60.7% 63,209 63,965
50% 49.9% 52,675 52,571
40% 39.5% 42,140 41,665
30% 29.9% 31,605 31,514
20% 19.8% 21,070 20,834
10% 10.1% 10,535 10,588
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
