Lenovo Global Technology Think System SR665 V3 ssj_ops@100% = 183,345
Test Sponsor: Lenovo Global Technology SPEC License #: 9017 Test Method: Single Node
Tested By: Lenovo Global Technology Test Location: Beijing, China Test Date: May 23, 2023
Hardware Availability: Aug-2023 Software Availability: Jun-2022 Publication: Jun 13, 2023
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     187,531
Calibration 2     181,772
Calibration 3     186,188
ssj_ops@calibrated=183,980
100% 99.7% 183,980 183,345
90% 90.8% 165,582 167,068
80% 80.1% 147,184 147,303
70% 69.5% 128,786 127,901
60% 59.5% 110,388 109,546
50% 49.2% 91,990 90,553
40% 39.9% 73,592 73,484
30% 29.9% 55,194 54,926
20% 19.9% 36,796 36,610
10% 9.7% 18,398 17,916
Active Idle   0 0
Graph of results
System Under Test
Set: 'sut'
Set Identifier: sut
Set Description: System Under Test
# of Identical Nodes: 1
Comment: 'SUT'
Hardware
Hardware Vendor: Lenovo Global Technology
Model: Think System SR665 V3
Form Factor: 2U
CPU Name: AMD EPYC 9754 2.25GHz
CPU Characteristics: 128-Core, 2.25GHz, 256MB L3 Cache
CPU Frequency (MHz): 2250
CPU(s) Enabled: 256 cores, 2 chips, 128 cores/chip
Hardware Threads: 512 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 1 MB I+D on chip per core
Tertiary Cache: 256 MB I+D on chip per chip, 32 MB shared / 8 cores
Other Cache: None
Memory Amount (GB): 384
# and size of DIMM: 24 x 16384 MB
Memory Details: 24 x 16GB 1Rx8 PC5-4800B-RD0; slots 1 to 24 populated
Power Supply Quantity and Rating (W): 1 x 1100
Power Supply Details: Lenovo P/N:4P57A72666
Disk Drive: 1 x 240GB M.2 SSD P/N:4XB7A82286 M.2 Module P/N:4Y37A79663
Disk Controller: Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x ThinkSystem 10/25GbE 2-Port Ethernet Adapter P/N:4XC7A08238
NICs Enabled in Firmware / OS / Connected: 2/2/1
Network Speed (Mbit): 10000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Enabled (see SUT Notes)
Operating System (OS): SUSE Linux Enterprise Server 15 SP4
OS Version: 5.14.21-150400.22-default
Filesystem: xfs
JVM Vendor: Oracle Corporation
JVM Version: Oracle Java HotSpot(TM) 64-Bit Server VM 18.9 (build 11.0.15.1+2-LTS-10, mixed mode), version 11.0.15.1
JVM Command-line Options: -server -Xmn1900m -Xms2048m -Xmx2048m -XX:SurvivorRatio=1 -XX:TargetSurvivorRatio=99 -XX:ParallelGCThreads=2 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=2 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParallelOldGC -XX:+UseHugeTLBFS -XX:+UseTransparentHugePages -XX:UseAVX=1 -XX:BiasedLockingStartupDelay=30000 -XX:LargePageSizeInBytes=2m
JVM Affinity: for each physicalCore { numactl -C physicalCoreId, physicalCoreId + 1, physicalCoreId + 256, physicalCoreId + 257 }
JVM Instances: 128
JVM Initial Heap (MB): 2048
JVM Maximum Heap (MB): 2048
JVM Address Bits: 64
Boot Firmware Version: KAE111F
Management Firmware Version: KAX317D
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: None
Boot Firmware Settings
Management Firmware Settings
none
System Under Test Notes
Notes
Performance Details
Target Load Actual Load Transaction Type Count Total Heap (MB)
Calibration 1 New Order 13,641,649 2,038
Payment 13,641,654
Order Status 1,364,164
Delivery 1,364,164
Stock Level 1,364,163
Customer Report 13,641,652
Calibration 2 New Order 13,219,769 2,038
Payment 13,219,770
Order Status 1,321,978
Delivery 1,321,977
Stock Level 1,321,977
Customer Report 13,219,768
Calibration 3 New Order 13,540,929 2,038
Payment 13,540,935
Order Status 1,354,092
Delivery 1,354,093
Stock Level 1,354,094
Customer Report 13,540,929
100% 99.7% New Order 13,334,289 2,038
Payment 13,334,289
Order Status 1,333,429
Delivery 1,333,430
Stock Level 1,333,429
Customer Report 13,334,289
90% 90.8% New Order 12,150,460 2,038
Payment 12,150,458
Order Status 1,215,048
Delivery 1,215,045
Stock Level 1,215,047
Customer Report 12,150,458
80% 80.1% New Order 10,713,445 2,038
Payment 10,713,445
Order Status 1,071,347
Delivery 1,071,346
Stock Level 1,071,344
Customer Report 10,713,450
70% 69.5% New Order 9,301,902 2,038
Payment 9,301,901
Order Status 930,192
Delivery 930,189
Stock Level 930,188
Customer Report 9,301,902
60% 59.5% New Order 7,966,986 2,038
Payment 7,966,983
Order Status 796,698
Delivery 796,697
Stock Level 796,699
Customer Report 7,966,985
50% 49.2% New Order 6,585,669 2,038
Payment 6,585,674
Order Status 658,568
Delivery 658,566
Stock Level 658,568
Customer Report 6,585,673
40% 39.9% New Order 5,344,348 2,038
Payment 5,344,342
Order Status 534,435
Delivery 534,436
Stock Level 534,436
Customer Report 5,344,351
30% 29.9% New Order 3,994,602 2,038
Payment 3,994,603
Order Status 399,461
Delivery 399,459
Stock Level 399,460
Customer Report 3,994,600
20% 19.9% New Order 2,662,553 2,038
Payment 2,662,550
Order Status 266,257
Delivery 266,254
Stock Level 266,254
Customer Report 2,662,549
10% 9.7% New Order 1,302,971 2,038
Payment 1,302,966
Order Status 130,297
Delivery 130,295
Stock Level 130,296
Customer Report 1,302,964
Active Idle New Order 0 2,038
Payment 0
Order Status 0
Delivery 0
Stock Level 0
Customer Report 0
