| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems Inc. |
| Hardware Available | Dec 1998 |
| Software Available | Oct 1998 |
| Date Tested | Mar 1999 |
| SFS License Number | 6 |
| Licensee Locations | Palo Alto, CA |
| CPU, Memory and Power |
|---|
| Model Name | Sun Enterprise 4500 |
| Processor | 400 MHz UltraSPARC II |
| # of Processors | 10 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 4MB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 12 GB |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Solaris7_64bit |
| Other Software | N/A |
| File System | UFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 559 |
| Fileset Size | 204.2 GB |
|
| Network Subsystem |
|---|
| Network Type | 1000Mbit Sun GigabitEthernet |
| Network Controller Desc. | Sun GigabitEthernet SBus adaptor 2.0 |
| Number Networks | 2 (N1-N2) |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | 2 SunSwitch |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 5 |
| Number of Disks | 230 |
| Number of Filesystems | 224 (F1-F224) |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | On-board SCSI-2 |
| # of Controller Type | 1 |
| Number of Disks | 6 |
| Disk Type | 4GB 7200rpm |
| File Systems on Disks | OS, swap |
| Special Config Notes | |
| Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
| # of Controller Type | 1 |
| Number of Disks | 56 |
| Disk Type | 9GB 7200rpm FC-AL |
| File Systems on Disks | F1-F14, F15-F28, F29-F42, F43-F56 |
| Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
| Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
| # of Controller Type | 1 |
| Number of Disks | 56 |
| Disk Type | 9GB 7200rpm FC-AL |
| File Systems on Disks | F57-F70, F71-F84, F85-F98, F99-F112 |
| Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
| Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
| # of Controller Type | 1 |
| Number of Disks | 56 |
| Disk Type | 9GB 7200rpm FC-AL |
| File Systems on Disks | F113-F126, F127-F140, F141-F154, F155-F168 |
| Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
| Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
| # of Controller Type | 1 |
| Number of Disks | 56 |
| Disk Type | 9GB 7200rpm FC-AL |
| File Systems on Disks | F169-F182, F183-F196, F197-F210, F211-F224 |
| Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
|
| Testbed Configuration |
|---|
| LG # | LG Type | Network | Target File Systems | Notes |
| 1/2/3/4 | LG1 | N1 | F1,F17,..,F209/F2,F18,..,F210/F3,F19,..,F211/F4,F20,..,F212 | N/A |
| 5/6/7/8 | LG1 | N1 | F5,F21,..,F213/F6,F22,..,F214/F7,F23,..,F215/F8,F24,..,F216 | N/A |
| 9/10/11/12 | LG1 | N2 | F9,F25,..,F217/F10,F26,..,F218/F11,F27,..,F219/F12,F28,..,F220 | N/A |
| 13/14/15/16 | LG1 | N2 | F13,F29,..,F221/F14,F30,..,F222/F15,F31,..,F223/F16,F32,..,F224 | N/A |
