| Server Configuration and Availability |
|---|
| Vendor | Hewlett Packard |
| Hardware Available | Oct 2001 |
| Software Available | Oct 2001 |
| Date Tested | Oct 2001 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | HP surestore NAS VA 105J |
| Processor | PA-8700@750Mhz |
| # of Processors | 2 |
| Primary Cache | 750KB Instruction, 1.5MB data on chip |
| Secondary Cache | N/A |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | Brocade Silkworm 2800 FC switch |
| Memory Size | 16 GB |
| NVRAM Size | 2GB |
| NVRAM Type | Double buffered |
| NVRAM Description | 3-days battery protection |
| Server Software |
|---|
| OS Name and Version | HP-UX 11.11 |
| Other Software | N/A |
| File System | JFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic 40-60% (see notes below) |
| # NFS Processes | 100 |
| Fileset Size | 134.6 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | PCI 1000Base-SX (A4926A) |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | HP Procurve Gigabit Switch 4108GL |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 3 |
| Number of Disks | 31 |
| Number of Filesystems | 10 (FS01-FS10) |
| File System Creation Ops | logsize=2048,bsize=8192,largefiles |
| File System Config | See notes below |
| Disk Controller | Ultra2 Wide SCSI (builtin) |
| # of Controller Type | 1 |
| Number of Disks | 1 |
| Disk Type | Seagate ST39204LC |
| File Systems on Disks | OS, swap, dump |
| Special Config Notes | N/A |
| Disk Controller | PCI Fiber Channel A5158A |
| # of Controller Type | 1 |
| Number of Disks | 30 |
| Disk Type | 18GB, 15000rpm ST318451FC |
| File Systems on Disks | FS01,FS02,FS03,FS04,FS05,FS06...FS10 |
| Special Config Notes | See notes below ... |
|
