| Server Configuration and Availability |
|---|
| Vendor | Hewlett-Packard |
| Hardware Available | Oct 2003 |
| Software Available | Oct 2003 |
| Date Tested | Oct 2003 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | HP Integrity Server rx7620 |
| Processor | Itanium 2 @ 1500 Mhz |
| # of Processors | 8 |
| Primary Cache | 16 KB + 16 KB (I + D) |
| Secondary Cache | 256 K |
| Other Cache | L3 Cache 6 MB |
| UPS | N/A |
| Other Hardware | Three HP16 FC Switches (2 gigabit mode) |
| Memory Size | 64 GB |
| NVRAM Size | 9 GB (1 GB/VA7400 * 9) |
| NVRAM Type | 1 GB battery backed NVRAM (3 day) |
| NVRAM Description | VA7400 Array controller |
| Server Software |
|---|
| OS Name and Version | HP-UX 11.23 |
| Other Software | N/A |
| File System | JFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic with ceiling at 63 percent |
| # NFS Processes | 216 |
| Fileset Size | 685.5 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | HP A6847 PCI 1000Base-SX |
| Number Networks | 6 |
| Number Network Controllers | 6 |
| Protocol Type | UDP |
| Switch Type | HP Procurve 4000M Gigabit |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 7 |
| Number of Disks | 379 |
| Number of Filesystems | 108 |
| File System Creation Ops | mkfs -F vxfs -bs 8192 -o logsize=2048 |
| File System Config | N/A |
| Disk Controller | Ultra160 Wide LVD A6793 |
| # of Controller Type | 1 |
| Number of Disks | 1 |
| Disk Type | HP 36.4GST336706LC |
| File Systems on Disks | os, swap, dump |
| Special Config Notes | N/A |
| Disk Controller | 2 Gbit Fibre channel A6795A |
| # of Controller Type | 2 |
| Number of Disks | 126 |
| Disk Type | 36GB, 15000 rpm |
| File Systems on Disks | F1,F7..F103/F2,F8..F104 |
| Special Config Notes | See notes below. |
| Disk Controller | 2 Gbit Fibre channel A6795A |
| # of Controller Type | 2 |
| Number of Disks | 126 |
| Disk Type | 36GB, 15000 rpm |
| File Systems on Disks | F3,F9..F105/F4,F10..F106 |
| Special Config Notes | See notes below. |
| Disk Controller | 2 Gbit Fibre channel A6795A |
| # of Controller Type | 2 |
| Number of Disks | 126 |
| Disk Type | 36GB, 15000 rpm |
| File Systems on Disks | F5,F11..F107/F6,F12..F108 |
| Special Config Notes | See notes below. |
|
